Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Factor Toray® & Nippon Graphite® Pan-Based Fiber
Suspension Fork
Factor LS carbon
Drivetrain
Rear Derailleur
Campagnolo Ekar
Cassette
Campagnolo Ekar 9-42T
Crank
Campagnolo Ekar 38T
Bottom Bracket
CeramicSpeed T47A Aluminum cups / CeramicSpeed bearings with Wheels MFG 24mm BBRight Reducers / Adapters
Wheels
Rims
700c
Brakes
Brakes
Hydraulic disc
Cockpit
Headset
1-1/8" upper, 1-3/8" lower
Seat
Seatpost
27.2 Round, post not included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.44 mm | 1.47 mm | 1.49 mm | 1.5 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Front Center | 582 mm | 589 mm | 597 mm | 612 mm | 627 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 60 mm | 60 mm | 59 mm | 59 mm | 59 mm |
| Stack | 534 mm | 551 mm | 570 mm | 589 mm | 609 mm |
| Reach | 376 mm | 382 mm | 387 mm | 396 mm | 405 mm |
| Top Tube Length | 523 mm | 539 mm | 554 mm | 570 mm | 584 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 481 mm | 507 mm | 527 mm | 552 mm |
| Head Tube Angle | 71.5 ° | 71.9 ° | 72.3 ° | 72.3 ° | 72.3 ° |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 994 mm | 1002 mm | 1009 mm | 1024 mm | 1039 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 752 mm | 776 mm | 793 mm | 813 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
LS Campagnolo Ekar is part of the Factor Ls model. There are 17 bikes that carry this model name. Take a sneak peek at all Factor Ls bikes models from 2023, by clicking here.
Model range prices
Factor LS 2023 is the most economical model, with a starting price of 2700$. Factor LS SRAM Force eTap AXS w/ Power Meter 2023 on the other hand costs 7499$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the LS Campagnolo Ekar model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The LS Campagnolo Ekar comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
