Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
25 CrMo 4, double butted
Suspension Fork
Columbus Futura Cross+, Carbon, 12 x 100 mm, Flatmount, tapered,
Drivetrain
Rear Derailleur
N.V.
Shift Levers
Campagnolo Ekar, 13-speed, Clutch lock
Cassette
Campagnolo Ekar, 13-speed, 10-44 teeth, N3W freewheel body
Crank
Campagnolo Ekar, Carbon, 40 teeth, (170 / 172,5 / 172,5 / 175 / 175 mm)
Chain
Campagnolo Ekar, 13-speed
Chain Guide
N.V.
Pedals
N.V.
Wheels
Front Hub
SON 28, 12 x 100 mm, hub dynamo, Centerlock, 32 holes
Rear Hub
Campagnolo, 12 x 142 mm, Centerlock, 32 holes, N3W
Rims
Campagnolo Ekar, Carbon, 40 teeth, (170 / 172,5 / 172,5 / 175 / 175 mm)
Spokes
Niro 2,0 mm black
Tires
Schwalbe G-One R, 45-622
Brakes
Brakes
Campagnolo Ekar (front 160 mm / rear 160 mm), Flatmount disc brake
Brake Levers
Campagnolo Ekar, 13-speed, Ultra-Shift
Cockpit
Stem
Ritchey C-220 WCS Aluminum, 6°, (70 / 70 / 70 / 90 / 90 mm)
Handlebar
Ritchey Butano WCS Aluminum, Flare 12°, (400 / 420 / 440 / 460 / 460 mm)
Grips
Brooks Cambium, 3,0 mm thick, black
Seat
Saddle
Brooks Carved C15, Carbon-Rail, 140 mm wide, black
Seatpost
Ritchey WCS Carbon Link Flexilogic, 27.2 mm, 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
GX-900 is part of the Fahrradmanufaktur Gx 900 model. Fahrradmanufaktur released 2 bikes variations of this model so far. Take a sneak peek at all Fahrradmanufaktur Gx 900 bikes models from 2023, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Gravel bikes average weight
If we make a quick analysis of the average weight of a Gravel bike, we get 8.45 kg (18.63 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 11.4 kg (25.13 lbs), Fahrradmanufaktur bike is much heavier than average. To sum up, it’s 34.91% heavier than the average weight of Gravel bikes.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the GX-900 model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Fahrradmanufaktur GX-900 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
