Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Fork RockShox ZEB Select
-
Groupset GX Eagle AXS, SRAM -
Suspension Full -
Motor Brose 250W 90Nm mid-drive -
Battery Fantic Integra, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Sizes: S - M - L
Suspension Fork
RockShox ZEB SELECT e-bike - 29" 170mm
Rear Shock
RockShox SuperDeluxe Select+ T205x60 Air
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS 12v
Shift Levers
SRAM GX Eagle AXS 12v
Cassette
SRAM SX Eagle 12V, 11-50
Crank
SRAM 34t Steel Eagle
Chain
SRAM SX Eagle 12V
Wheels
Rims
FULCRUM E-500 29"-27.5"
Tires
Front: Vittoria E-MARTELLO 29"x 2.35, Rear: Vittoria E-MARTELLO 27,5"x 2.6
Brakes
Brakes
Magura MT7 4 Piston disc brake
Cockpit
Stem
FSA GRADIENT Ø35 Rise +6° 50mm
Handlebar
FSA COMET Ø35 Rise 20 800mm
Seat
Saddle
Selle Italia Novus Boost X-CROSS Superflow
Seatpost
Rockshox Reverb Ø 30.9 S-M(100mm), L(125mm)
Motor & Battery
Motor
Brose S-MAG 36 Volt, Max power: 250 Watt, Torque/Coppia: 90 Nm
Battery
Fantic Integra, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 361.5 mm | 361.5 mm | 361.5 mm |
| Reach | 397.5 mm | 428.5 mm | 453 mm |
| Top Tube Length | 578.5 mm | 613 mm | 640 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm |
| Head Tube Angle | 64 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1202 mm | 1231 mm | 1253 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
XMF 1.7 Carbon Race belongs to the Fantic E Xmf model. 6 e-bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
XMF 1.7 Carbon Race components
Fork
The XMF 1.7 Carbon Race comes factory-installed with the RockShox ZEB Select fork. This has a travel range of 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the XMF 1.7 Carbon Race model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fantic XMF 1.7 Carbon Race is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Fantic XMF 1.7 Carbon Race e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Fantic model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
