Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, SRAM -
Suspension Full -
Motor Brose 250W 90Nm mid-drive -
Battery Fantic Integra, Lithium Ion, 36 Volt, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
RockShox RECON Silver RL e-bike - 29" 150mm
Rear Shock
RockShox Deluxe Select T205x57,5 Air
Drivetrain
Rear Derailleur
SRAM SX Eagle 12V
Shift Levers
SRAM SX E-click
Cassette
SRAM SX Eagle 12V, 11-50
Crank
SRAM 34t Steel Eagle
Chain
SRAM SX Eagle 12V
Wheels
Rims
Rodi BlackJack TRIP30
Tires
Front: Schwalbe SMARTSAM 29"x 2.4, Rear: Schwalbe SMARTSAM 29"x 2.4
Brakes
Brakes
SRAM LEVEL 2 Piston disc brake
Cockpit
Stem
GBC-MAS-D6293-60MM±8°-ø31,8
Handlebar
GBC-MHB-760MM-RISE-20mm
Seat
Saddle
Selle Italia MODEL-X Comfort Superflow 145
Seatpost
Promax teles. SP -2038 Ø 30.9, S 80mm (SWITCH)/ M-L 100mm
Motor & Battery
Motor
Brose S-ALU 36 Volt, Max power: 250 Watt, Torque/Coppia: 90 Nm
Battery
Fantic Integra, Lithium Ion, 36 Volt, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 358 mm | 358 mm | 358 mm |
| Stack | 622.8 mm | 632 mm | 648.5 mm |
| Reach | 414 mm | 440 mm | 460 mm |
| Top Tube Length | 580 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66.5 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 479 mm | 479 mm | 479 mm |
| Wheelbase | 1200 mm | 1231 mm | 1251 mm |
| Bottom Bracket Drop | 16 mm | 16 mm | 16 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
XTF 1.5 is a Fantic E Xtf model. There are 17 e-bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
XTF 1.5 components
Fork
Fantic XTF 1.5 2022 e-bike is equipped with the RockShox Recon Silver RL fork, and has 150mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on XTF 1.5 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The XTF 1.5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
XTF 1.5 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
