Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle, SRAM -
Suspension Full -
Motor Brose 250W 90Nm mid-drive -
Battery Fantic Integra, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Sizes: S - M - L - XL
Suspension Fork
RockShox 35 GOLD RL e-bike - 29" 150mm
Rear Shock
RockShox Deluxe Select+ T205x60 Air
Drivetrain
Rear Derailleur
SRAM NX Eagle 12V
Shift Levers
SRAM NX E-click
Cassette
SRAM SX Eagle 12V, 11-50
Crank
SRAM 34t Steel Eagle
Chain
SRAM SX Eagle 12V
Wheels
Rims
Rodi BlackJack READY27, F 29"/R 29"
Tires
Front: Pirelli SCORPION ProWall Trail -M- 29"x 2.4, Rear: Pirelli SCORPION ProWall Trail -R- 29"x 2.4
Brakes
Brakes
SRAM GUIDE T 4 Piston disc brake
Cockpit
Stem
FSA Logo 60mm-31,8 RISE6°
Handlebar
FSA Logo 760mm-31,8 RISE15 SWEEP 6°
Seat
Saddle
Selle Italia MODEL-X Comfort Superflow 145
Seatpost
Switch SW Ø 30.9 S-M(100mm), L(125mm), XL(150mm)
Motor & Battery
Motor
Brose S-MAG 36 Volt, Max power: 250 Watt, Torque/Coppia: 90 Nm
Battery
Fantic Integra, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 362.5 mm | 362.5 mm | 362.5 mm | 362.5 mm |
| Stack | 615 mm | 622.1 mm | 635.9 mm | 652.5 mm |
| Reach | 426 mm | 445 mm | 473 mm | 495 mm |
| Top Tube Length | 582 mm | 603 mm | 635 mm | 662 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 469 mm | 510 mm |
| Head Tube Angle | 66 ° | 66.5 ° | 66.5 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1195 mm | 1211 mm | 1245 mm | 1267 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
XTF 1.5 Carbon is a Fantic E Xtf model. There are 17 e-bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the RockShox 35 Gold RL model. The travel on this model is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on XTF 1.5 Carbon are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The XTF 1.5 Carbon has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
