Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Fork RockShox 35 Gold RL
-
Groupset NX, NX Eagle -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Sizes: S-M -L-XL
Suspension Fork
RockShox 35 Gold RL 150mm
Rear Shock
RockShox Deluxe Select+
Drivetrain
Rear Derailleur
SRAM NX
Shift Levers
SRAM NX Eagle
Cassette
SRAM SX, 12V, 11-51
Crank
SRAM 34t
Chain
SRAM SX
Wheels
Rims
Rodi READY27- 29"
Tires
Pirelli SCORPION ProWall Trail -R- 29"x 2.4
Brakes
Brakes
SRAM GUIDE T 4 Piston disc brake
Cockpit
Stem
FSA Logo-60mm- Ø31,8 - Rise +6°
Handlebar
FSA 760mm- Ø31,8 - Rise 15mm - Sweep 6°
Seat
Saddle
Selle Italia MODEL-X Comfort Superflow 145
Seatpost
Switch SW Ø 30.9
Motor & Battery
Motor
Brose S-Mag 36, Torque/Coppia: 90 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 362.5 mm | 362.5 mm | 362.5 mm | 362.5 mm |
| Stack | 615 mm | 622.1 mm | 635.9 mm | 652.5 mm |
| Reach | 426 mm | 445 mm | 473 mm | 495 mm |
| Top Tube Length | 582 mm | 603 mm | 635 mm | 662 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 469 mm | 510 mm |
| Head Tube Angle | 66 ° | 66.5 ° | 66.5 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1195 mm | 1211 mm | 1245 mm | 1267 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
XTF 1.5 Carbon is part of the Fantic E Xtf model. 17 e-bikes variations carry this model name so far. You can easily view all of the Fantic E Xtf e-bikes models from 2023, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
XTF 1.5 Carbon components
Fork
The XTF 1.5 Carbon comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The XTF 1.5 Carbon 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Fantic XTF 1.5 Carbon has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
