Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Fork RockShox 35 Gold RL
-
Groupset GX Eagle AXS, SRAM -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 630Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
RockShox 35 Gold RL 150mm
Rear Shock
RockShox Deluxe Select+
Drivetrain
Rear Derailleur
SRAM GX AXS
Shift Levers
SRAM GX AXS Eagle
Cassette
SRAM SX, 12V, 11-50
Crank
SRAM 34t
Chain
SRAM SX
Wheels
Rims
Rodi TRYP30
Tires
Pirelli SCORPION TRAIL -R- 29"x 2.4
Brakes
Brakes
SRAM GUIDE T 4 Piston disc brake
Cockpit
Stem
FSA Logo Ø31,8 - Rise +6°
Handlebar
FSA Ø31,8 - Rise15mm - Sweep 6°
Seat
Saddle
Selle Italia MODEL-X Comfort Superflow 145
Seatpost
SWITCH SW Ø 30.9, S - 80mm / M - 100mm / L - 125mm
Motor & Battery
Motor
Brose S-Alu, Torque/Coppia: 90 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 358 mm | 358 mm | 358 mm |
| Reach | 414 mm | 440 mm | 460 mm |
| Top Tube Length | 580 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66.5 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 479 mm | 479 mm | 479 mm |
| Wheelbase | 1200 mm | 1231 mm | 1251 mm |
| Bottom Bracket Drop | 16 mm | 16 mm | 16 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
XTF 1.5 Race is part of the Fantic E Xtf model. Fantic launched 17 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The XTF 1.5 Race comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Fantic XTF 1.5 Race 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The XTF 1.5 Race has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
