Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Fork RockShox Lyrik Select
-
Groupset GX Eagle, NX -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Sizes: S-M-L-XL
Suspension Fork
RockShox Lyrik Select 160mm
Rear Shock
RockShox Deluxe Select+
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX
Cassette
SRAM SX, 12V, 11-50
Crank
SRAM 34t
Chain
SRAM SX
Wheels
Rims
Rodi READY27 - 29"
Tires
Pirelli SCORPION ProWall Trail -R- 29"x 2.4
Brakes
Brakes
SRAM G2 RS 4 Piston disc brake
Cockpit
Stem
FSA 60mm- Ø31,8 - Rise +6°
Handlebar
FSA 760mm- Ø31,8 - Rise 15mm - Sweep 6°
Seat
Saddle
Selle Italia X BOW Superflow
Seatpost
Switch SW Ø 30.9
Motor & Battery
Motor
Brose S-Mag 36, Torque/Coppia: 90 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.4 mm | 1.34 mm | 1.32 mm |
| Bottom Bracket Height | 362.5 mm | 362.5 mm | 362.5 mm | 362.5 mm |
| Stack | 615 mm | 622.1 mm | 635.9 mm | 652.5 mm |
| Reach | 426 mm | 445 mm | 473 mm | 495 mm |
| Top Tube Length | 582 mm | 603 mm | 635 mm | 662 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 469 mm | 510 mm |
| Head Tube Angle | 66 ° | 66.5 ° | 66.5 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1195 mm | 1211 mm | 1245 mm | 1267 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
XTF 1.6 Carbon Sport is a Fantic E Xtf model. There are 17 e-bikes that carry this model name. You can easily view all of the Fantic E Xtf e-bikes models from 2023, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The RockShox Lyrik Select is included from the factory. It has a travel distance of 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the XTF 1.6 Carbon Sport e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fantic XTF 1.6 Carbon Sport is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
