Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 200mm -
Fork RockShox BoXXer
-
Groupset NX Eagle, SRAM -
Suspension Full -
Motor Brose 250W 90Nm mid-drive -
Battery Fantic Integra, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
RockShox BOXXER Selct e-bike - 29" 200mm
Rear Shock
RockShox SuperDeluxe Coil Select+ T205x65
Drivetrain
Rear Derailleur
SRAM NX Eagle 12V
Shift Levers
SRAM NX E-click
Cassette
SRAM SX Eagle 12V, 11-50
Crank
SRAM 34t Steel Eagle
Chain
SRAM NX Eagle 12V
Wheels
Rims
Mavic E-XM
Tires
Front: Vittoria E-MAZZA 29"x 2.6, Rear: Vittoria E-MARTELLO 27,5"x 2.8
Brakes
Brakes
Magura MT7 4 Piston disc brake
Cockpit
Stem
FSA DIRETTO 45mm-35
Handlebar
FSA Gradient 800mm-35 RISE25
Seat
Saddle
Sella Italia Novus Boost Model X Comfort Superflow
Seatpost
SWITCH SW Ø 30.9 S-M(100mm), L(125mm)
Motor & Battery
Motor
Brose S-MAG 36 Volt, Max power: 250 Watt, Torque/Coppia: 90 Nm
Battery
Fantic Integra, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 368 mm | 370 mm | 370 mm |
| Reach | 423 mm | 452.5 mm | 478.5 mm |
| Top Tube Length | 595.5 mm | 626 mm | 656 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1233 mm | 1263 mm | 1288 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
XXF 2.0 Race is a Fantic E Xxf model. There are 4 e-bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Downhill e-bikes average price
Our math shows that the average cost of a dependable Downhill e-bike is 5530$. However, you could also get a good Downhill e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
XXF 2.0 Race components
Fork
The RockShox BoXXer is included from the factory. It has a travel distance of 200mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Fantic XXF 2.0 Race 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Fantic XXF 2.0 Race has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
XXF 2.0 Race comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
