Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 200mm -
Fork RockShox BoXXer Select
-
Groupset NX, NX Eagle -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
RockShox Boxxer Select, 200mm
Rear Shock
RockShox SuperDeluxe Coil Select+
Drivetrain
Rear Derailleur
SRAM NX
Shift Levers
SRAM NX Eagle
Cassette
SRAM SX Eagle 12V, 11-50
Crank
SRAM 34t
Chain
SRAM NX
Wheels
Rims
MAVIC E-DEEMAX 29"- 27.5"
Tires
Vittoria E-MARTELLO 27,5"x 2.8
Brakes
Brakes
Magura MT7 4 Piston disc brake
Cockpit
Stem
FSA Gradient Direct - Ø35 - 45mm
Handlebar
FSA Gradient-800mm- Ø35 - Rise 25mm
Seat
Saddle
Selle Italia Model-X Comfort Superflow
Seatpost
SWITCH SW Ø 30.9
Motor & Battery
Motor
Brose S-Mag, Torque/Coppia: 90 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 368 mm | 370 mm | 370 mm |
| Reach | 423 mm | 452.5 mm | 478.5 mm |
| Top Tube Length | 595.5 mm | 626 mm | 656 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1233 mm | 1263 mm | 1288 mm |
| Bottom Bracket Drop | -13 mm | -15 mm | -15 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
XXF 2.0 Race is part of the Fantic E Xxf model. Fantic launched 4 e-bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Downhill e-bikes average price
According to our math, the average price for a trustworthy Downhill e-bike is 5530$. However, this doesn’t mean that if you spend less money on a Downhill e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
XXF 2.0 Race components
Fork
Fantic XXF 2.0 Race 2023 e-bike is equipped with the RockShox BoXXer Select fork, and has 200mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The XXF 2.0 Race 2023 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The XXF 2.0 Race comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
