Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Ultimate + Nano MMC carbon fiber w/ 1.5KP weave, InsideOut internal molding process, machined threaded aluminum BB shell, internal Di2 or mechanical cable routing, carbon fiber dropouts & 7075 CNC machined aluminum replaceable derailleur hanger
Suspension Fork
Felt Aero Road UHC Ultimate + Nano monocoque fork, 100% carbon fiber 1.125"" steerer tube, crown, blades, & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2
Front Derailleur
Shimano Dura-Ace Di2 braze-on
Shift Levers
Shimano Dura-Ace Di2 STI
Cassette
Shimano 11-25T
Crank
Shimano Dura-Ace, 53/39T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
Shimano Hollowtech-II
Chain
Shimano 10 speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano Dura-Ace forged aluminum loose ball 16H w/ Shimano Dura-Ace quick release
Rear Hub
Shimano Dura-Ace forged aluminum loose ball w/ 10 speed HG titanium freehub body w/ Shimano Dura-Ace quick release
Rims
Shimano WH-7900-C35-CL 35mm deep carbon fiber clincher, 16H front, 20H rear
Spokes
Shimano Dura-Ace 16H x 275mm front, 10 x 294mm drive rear& 10 x 295mm non-drive rear bladed aero stainless steel w/ aluminum nipples
Tires
Vittoria Diamante Pro Light, 700c x 23c
Brakes
Brakes
Shimano Dura-Ace Super SLR dual pivot w/ cartridge brake pads
Brake Levers
Shimano Dura-Ace Di2 STI
Cockpit
Stem
Devox 7050 aluminum 3D forged +/-7° rise, Ø31.8mm bar clamp, titanium bolts, 118g; 51cm=90mm, 54cm=100mm, 56cm=100mm, 58cm=110mm, 61cm=120mm
Handlebar
Devox VS UHC Ultimate + Nano DMC carbon fiber bar w/ 1.5KP weave w/ Felt Variable Shape ergonomic drop, 172g, Ø31.8mm, 51cm=400mm, 54cm=420mm, 56cm-61cm=440mm
Grips
Devox gel velvet tape w/ Devox 3D logo
Headset
FSA Orbit IS Carbon integrated, w/ carbon fiber 15mm conical spacer, 2 X 10mm carbon fiber headset spacers, 1 x 5mm aluminum headset spacer, Felt carbon fiber top cap & 7075 anodized aluminum bolt
Seat
Saddle
Devox Team Issue w/ 100% 3k carbon fiber weave base, microfiber cover & 3k UHC carbon fiber rails, 159 gm
Seatpost
Felt Aero UHC Advanced carbon fiber standard offset bladed monocoque design, length = 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.41 mm | 1.45 mm | 1.47 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 578 mm | 581 mm | 584.32 mm | 598 mm | 620 mm |
| Rake | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 56 mm | 55 mm | 56 mm | 52 mm |
| Stack | 510 mm | 531 mm | 553 mm | 572 mm | 593 mm |
| Reach | 376 mm | 377 mm | 381 mm | 389 mm | 410 mm |
| Top Tube Length | 521 mm | 536 mm | 551.12 mm | 566 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.125 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 403 mm | 403 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 971 mm | 974 mm | 980 mm | 993 mm | 1016 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 740 mm | 765 mm | 785 mm | 789 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR1 belongs to the Felt Ar1 model. There are 16 bikes that carry this model name. Take a sneak peek at all Felt Ar1 bikes models from 2012, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2012 and its price was 9999$. Comparing this to the average Aero bike price, we see that the price is 137.45% higher.
Aero bikes average weight
Aero bikes have an average weight of 7.34 kg (16.18 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Felt AR1 it’s weighing 6.79 kg (14.97 lbs). At this weight, is a bit lighter than average. In short, the average Aero bike weight is 8.1% higher than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
AR1 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the AR1 bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
