Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Advanced MMC Carbon Fiber Frame w/ 3KP Weave, Mechanically Optimized Internal Cable Routing, Carbon Fiber dropouts & Forged replaceable derailleur hanger
Suspension Fork
Felt AR UHC Performance 100% Carbon Fiber Fork; Carbon 1.125 Steerer tube, Crown, Blades, and Dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 SS Short Cage
Front Derailleur
Shimano 105 braze-on, double
Shift Levers
Shimano 105 STI, 20-Speed
Cassette
Shimano 105 Cassette, 11-25T
Crank
FSA Gossamer Pro Compact 2 piece w/ Integrated MegaExo BB, A6061-T6 cold Forged solid Crank Arms w/ AL7075 T6 Aluminum N10 5mm CNC Super Chainrings, Black AL7075 T6 Aluminum Torx T-30 Chainring Bolts, 110mm BCD, 808 grams (excluding BB) 50/34T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
FSA Mega EXO
Chain
Shimano 105 10-Speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TTR3 Sealed Bearing CNC Machined 7075 Aluminum 24H w/ Cr-Mo Quick Release Skewer
Rear Hub
Felt TTR3 Sealed Bearing CNC Machined 7075 Aluminum 28H w/ Cr-Mo Quick Release Skewer
Rims
Felt AeroR3 700c 30mm Deep Aluminum w/ CNC Machined Braking Surface, 24H Front/28H Rear
Spokes
Stainless Steel Bladed, Butted 2.0/0.9 x 2.3/1.8mm w/ Aluminum Nipples
Tires
Vittoria Zaffiro Pro, 700c x 23c, 60tpi
Brakes
Brakes
Tektro Quartz R741 Cold Forged Shimano Super SLR Compatible Dual Pivot w/ Cartridge Brake Shoes
Brake Levers
Shimano 105 STI
Cockpit
Stem
Felt SL 6061 Aluminum 3D Forged +/-7° Rise, Ø31.8mm Bar Clamp, custom Cr-Mo bolts, 128g, 51cm=90mm, 54cm=100mm, 56cm=100mm, 58cm=110mm, 61cm=120mm.
Handlebar
Felt VS Aero 2014 Triple Butted Aluminum w/ Aerodynamic Wing Top Section, w/ Ergonomic Drop, Ø31.8mm, 51cm=400mm, 54cm-56cm=420mm, 58cm-61cm=440mm
Grips
Felt Gel Ribbon Cork Tape w/ Felt 3D Logo
Headset
FSA Integrated, w/ Aluminum 25mm Conical Spacer, 2 X 10mm Aluminum Headset Spacers, Felt Aluminum Top Cap & 7075 Anodized Aluminum Bolt
Seat
Saddle
Felt SL Road Saddle w/ Carbon Fiber Injection Molded Base, Superlight Multi-Density Foam, Embossed Cover & Hollow Cr-Mo rails
Seatpost
Felt Aero UHC Advanced Carbon Fiber Standard Offset Bladed Monocoque Design, Length = 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.4 mm | 1.441 mm | 1.46 mm | 1.437 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 578 mm | 581 mm | 584 mm | 598 mm | 620 mm |
| Rake | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Stack | 519.5 mm | 540.3 mm | 561.6 mm | 580.8 mm | 601.7 mm |
| Reach | 384.8 mm | 385.9 mm | 389.6 mm | 397.7 mm | 418.8 mm |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 412 mm | 412 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 980 mm | 983 mm | 989 mm | 1002 mm | 1025 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 749 mm | 774 mm | 794 mm | 798 mm | 816 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR5 completes the Felt Ar5 model. 9 bikes variations carry this model name so far. You can easily view all of the Felt Ar5 bikes models from 2011, here.
Model range prices
Felt AR5 – 2012 2011 is the cheapest bike model and costs 2499$. Felt AR5 2011 is the most expensive one and costs 2799$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Aero bikes
Our math shows that the average cost of a dependable Aero bike is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2011 and its price was 2799$. Doing a quick comparison, we notice that AR5 price is 50.45% smaller than the average cost of an Aero bike.
Aero bikes average weight
The average weight for Aero bikes is 7.34 kg (16.18 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
a bit heavier than average, AR5 has a weight of 8.06 kg (17.77 lbs). To sum up, it’s 9.81% heavier than the average weight of Aero bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on AR5 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AR5 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
