Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival, SRAM -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Dual Aero TT / Tri UHC Performance carbon fiber, MMC w/ InsideOut construction, BB30 & horizontal dropouts w/ integrated chain tensioners, internal cable routing (electronic compatible)
Suspension Fork
Felt Aero TT / Tri UHC Performance carbon fiber blades & dropouts, 1.125" aluminum steerer tube
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Rival short cage
Front Derailleur
SRAM Rival braze-on
Shift Levers
SRAM TT 500
Cassette
SRAM, 11-28T
Crank
SRAM S350 BB30 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm
Bottom Bracket
SRAM BB30
Chain
SRAM 10-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt R3, sealed bearing, 24H
Rear Hub
Felt R3, sealed bearing, 28H, 10-speed
Rims
Felt TTR4
Spokes
2.0mm stainless steel
Tires
Vittoria Zaffiro Slick, 700 x 23c
Brakes
Brakes
Felt Aero TT / Tri
Brake Levers
Aero TT / Tri
Cockpit
Stem
Felt SuperLite, +/-7° rise, Ø31.8mm 51cm = 80mm 54 - 56cm = 90mm 58cm = 100mm 61cm = 110mm
Handlebar
Felt Aero TT/Tri base bar w/ Felt ƒ-Bend 3-position extensions, Ø31.8mm 51 - 54cm = 390mm 56 - 61cm = 420mm
Grips
Devox VelvetGel Tape, Felt Tri Tip Grips & Dimpled Gel Pads
Headset
FSA IS integrated, 1.125" sealed cartridge bearing w/ aluminum 9mm cone spacer, 20mm optional secondary cone spacer, 2 x 10mm + 1 x 5mm PC headset spacers & Felt top cap
Seat
Saddle
Felt TT / Tri
Seatpost
Felt DA/B Aero UHC carbon fiber, 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.25 mm | 1.34 mm | 1.32 mm | 1.32 mm | 1.31 mm | 1.35 mm |
| Bottom Bracket Height | 291 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 565 mm | 577 mm | 593 mm | 614 mm | 635 mm | 652 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 73 mm | 64 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Stack | 470 mm | 523 mm | 537 mm | 556 mm | 575 mm | 604 mm |
| Reach | 377 mm | 390 mm | 407 mm | 422 mm | 438 mm | 446 mm |
| Top Tube Length | 492 mm | 520 mm | 541 mm | 561 mm | 581 mm | 596 mm |
| Seat Tube Angle | 76.5 ° | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 470 mm | 510 mm | 540 mm | 560 mm | 580 mm | 510 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 115 mm | 115 mm | 127 mm | 147 mm | 167 mm | 198 mm |
| Chainstay Length | 377 mm | 397 mm | 397 mm | 397 mm | 397 mm | 397 mm |
| Wheelbase | 937 mm | 963 mm | 980 mm | 1001 mm | 1022 mm | 1039 mm |
| Bottom Bracket Drop | 45 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 705 mm | 745 mm | 766 mm | 781 mm | 782 mm | 782 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
About this model
B14 belongs to the Felt B14 model. 8 bikes variations carry this model name so far. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
Felt B14 W 2014 is the most affordable bike of this model and has a price of 2199$. On the other hand, Felt B14 2014, is the most expensive and costs 2199$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Triathlon bikes average price
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, you could also get a good Triathlon bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Felt released this model in 2014, its price was 2199$. Comparing the average cost of a Triathlon bike to this one, you will see that B14 price is 89.95% smaller.
Triathlon bikes average weight
On a deeper look, we notice that the average weight of a Triathlon bike is 8.9 kg (19.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
B14 weighs 9.2 kg (20.28 lbs) and is slightly heavier than the average. In conclusion, the average Triathlon bike weighs 3.37% less than B14.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
B14 components
Fork material
B14 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Felt B14 2014, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The B14 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Felt B14 bike has 6 sizes, in the range of 152 cm – 196 cm (4.99 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
