Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Alivio, SLX -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Fat, double-butted 6061 aluminum, Hydroform, ControlTaper integrated head tube, post disc mount, replaceable derailleur hanger, 100mm threaded bottom bracket, 190mm OLD, Ø30.9mm seatpost, Ø34.9mm clamp adaptor for high direct type front derailleur mount
Suspension Fork
Felt Fat hydroformed integrated 6061 aluminum, tapered steerer, 150 x 15mm front axle, post style disc mounts, rack mounts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Alivio long cage
Front Derailleur
Shimano SLX dual pull, high direct mount attached to band clamp & adaptor for 100mm BB
Shift Levers
Shimano Deore Rapid-Fire 3 x 9-speed
Cassette
Sunrace 9-speed 11-36 T
Crank
RaceFace Ride fat double: SM - 170mm MD/LG - 175mm
Bottom Bracket
ISIS Taper 100MM
Chain
Sunrace
Chain Guide
n/a
Pedals
Low-profile nylon platform
Wheels
Front Hub
Alloy Sealed bearing 6-bolt, 15 x 150mm OLD
Rear Hub
Alloy Sealed bearing 6-bolt, 12 x 197mm OLD
Rims
Single-wall i75, 26"
Spokes
2.0mm stainless steel
Tires
Schwalbe Jumbo Jim Light Skin 26" x 4"
Brakes
Brakes
Front Brake: Tektro Novella mechanical disc w/ 180mm rotor Rear Brake: Tektro Novella mechanical disc w/ 160mm rotor
Brake Levers
Tektro MTB
Cockpit
Stem
Felt MTB 3D-forged threadless 1-1/8" +/- 7° rise for Ø31.8mm handlebar w/ black Cr-Mo bolts: SM - 60mm MD - 70mm LG - 80mm
Handlebar
Felt MTB double-butted 6061 aluminum, Ø31.8mm, 5mm rise x 9° sweep, 720mm width
Grips
Felt Wing Grip, double-density
Headset
FSA No.57E/62 semi Integrated internal upper cup, external lower cup
Seat
Saddle
Felt MTB performance
Seatpost
Felt butted 6061 aluminum w/ 2-bolt micro-adjust 15mm offset: SM - Ø30.9 x 350mm MD/LG - Ø30.9 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.4 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 278 mm |
| Front Center | 642 mm | 673 mm | 704 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 77 mm | 77 mm |
| Stack | 605 mm | 619 mm | 634 mm |
| Reach | 402 mm | 428 mm | 454 mm |
| Top Tube Length | 586 mm | 616 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 470 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 120 mm | 135 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1096 mm | 1126 mm | 1157 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Double Double 70 belongs to the Felt Double model. Felt released 2 bikes variations of this model so far. Take a sneak peek at all Felt Double bikes models from 2015, by clicking here.
Model range prices
The most economical model, the Felt Double Double 70 2015 has a starting price of 1399$. Felt Double Double 30 2015 on the other hand is the most expensive at 1999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fatbike bikes average price
According to our calculations, the average cost of a Fatbike bike that is reliable is 1743$. However, this doesn’t mean that if you spend less money on a Fatbike bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1399$. In conclusion, this bike price is 24.59% smaller than the price of the average Fatbike bike.
Overview of components
Fork material
Double Double 70 has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The wheels on Double Double 70 are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Felt Double Double 70 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
