Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Race Road UHC Advanced + TeXtreme® carbon fiber, MMC with InsideOut construction, carbon fiber BB386 bottom bracket shell and carbon fiber dropouts, 7075 CNC aluminum replaceable rear derailleur hanger, mechanical (external) or electronic (internal) cable routing
Suspension Fork
Felt Race Road UHC Advanced + TeXtreme carbon fiber monocoque construction, size specific ControlTaper carbon fiber steer tube with integrated compression device and carbon fiber crown race, crown, blades and dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra 6800 Short Cage short cage
Front Derailleur
Shimano Ultegra 6800 Braze-on
Shift Levers
Shimano Ultegra 6800
Cassette
Shimano CS-5800 11-speed, 11-28T
Crank
Shimano Ultegra 6800 48cm = 165mm 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm
Bottom Bracket
Token For BB386 Frame with Shimano Crankset
Chain
Shimano11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Shimano WH-RS21
Rear Hub
Shimano WH-RS21, 11-speed
Rims
Shimano WH-RS21
Spokes
WH-RS21
Tires
Schwalbe DURANO RaceGuard, 700c x 25c
Brakes
Brakes
Shimano Ultegra 6800 dual pivot caliper
Brake Levers
Shimano Ultegra 6800
Cockpit
Stem
3T ARX II Pro Grey, ±6° rise, Ø31.8mm 43 - 51cm = 90mm 54 - 56cm = 100mm 58cm = 110mm 61cm = 120mm
Handlebar
3T Ergosum Pro Grey, 89mm reach, 128mm drop, Ø31.8mm 43 - 51cm = 400mm 54 - 56cm = 420mm 58 - 61cm = 440mm
Grips
Felt VelvetGel Tape with 3M Reflective Base
Headset
43 - 47cm: FSA IS-21 integrated, 1.125"" sealed cartridge bearing ; 51 - 54cm: FSA NO.382, 1.125""- 1.25"" sealed cartridge bearing; 56 - 61cm: FSA NO.38/42, 1.125"" - 1.5"" sealed cartridge bearing ; with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1 x 10mm + 2 x 5mm PC headset spacers, Felt carbon fiber top cap and aluminum bolt
Seat
Saddle
Prologo Nago Evo PAS T2.0
Seatpost
Felt UHC Performance carbon fiber, Ø27.2mm, 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.44 mm | 1.46 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 577 mm | 585 mm | 591 mm | 606 mm | 621 mm |
| Rake | 52 mm | 47 mm | 47 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 58 mm | 54 mm | 55 mm | 53 mm | 52 mm |
| Stack | 503 mm | 521 mm | 541 mm | 563 mm | 585 mm | 612 mm |
| Reach | 360 mm | 368 mm | 376 mm | 385 mm | 396 mm | 405 mm |
| Top Tube Length | 503 mm | 521 mm | 539 mm | 554 mm | 574 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 425 mm | 465 mm | 505 mm | 525 mm | 555 mm | 595 mm |
| Head Tube Angle | 71.5 ° | 72.25 ° | 73 ° | 73.5 ° | 73.75 ° | 74 ° |
| Head Tube Length | 100 mm | 115 mm | 135 mm | 155 mm | 177 mm | 205 mm |
| Chainstay Length | 394 mm | 394 mm | 396 mm | 396 mm | 398 mm | 401 mm |
| Wheelbase | 958 mm | 960 mm | 971 mm | 977 mm | 994 mm | 1012 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 667 mm | 701 mm | 738 mm | 758 mm | 781 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
Model Overview
FR3 is part of the Felt Fr3 model. Felt launched 6 bikes of this model so far. Take a sneak peek at all Felt Fr3 bikes models from 2017, by clicking here.
Model range prices
Felt FR3 2017 is the most affordable bike of this model and has a price of 2999$. On the other hand, Felt FR3 Disc 2017, is the most expensive and costs 3499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
Our math shows that the average cost of a dependable Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2017 and its price was 2999$. Comparing this to the average Race bike price, we see that the price is 11.7% smaller.
Race bikes average weight
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
considerably heavier than average, FR3 has a weight of 7.65 kg (16.87 lbs). In other words, this model is 12.17% heavier than the average Race bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Felt FR3 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 6 sizes. They vary from 152 cm – 196 cm (4.99 ft – 6.43 ft). In short, it won’t be difficult to find the right one for you.
