Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Race Road UHC Advanced + TeXtreme carbon fiber, MMC with InsideOut construction, carbon fiber BB386 bottom bracket shell, carbon fiber dropouts, CNC aluminum replaceable rear derailleur hanger, external mechanical or internal electronic cable routing
Suspension Fork
Felt Race Road UHC Advanced + TeXtreme carbon fiber monocoque construction, size specific ControlTaper carbon fiber steerer tube, integrated crown race, crown, blades and dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra R8000 11-speed short cage
Front Derailleur
Shimano Ultegra R8000 braze-on
Shift Levers
Felt VelvetGel tape with 3M reflective base with reflective Felt Bubble-Tech F-Wing bar end plugs Shimano Ultegra R8000 11-speed with Felt Elite sealed derailleur cable and housing
Cassette
Shimano 11-speed, 11-28T
Crank
Shimano Ultegra R8000, 52/36T, 43 - 47cm: 165mm -- 51cm: 170mm --- 54 - 56cm: 172.5mm --- 58 - 61cm: 175mm
Bottom Bracket
Token BB386 with 24mm bearings
Chain
Shimano 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
DT Swiss 370, 100mm QR
Rear Hub
DT Swiss 370, 11-speed, 130mm QR
Rims
DT Swiss F1825 Classic, tubeless ready, 18mm inner width, 23mm depth; 1845g (wheelset)
Spokes
DT Swiss Champion 2.0
Tires
Vittoria Rubino Pro G+ folding, 700 x 25c
Brakes
Brake Levers
Shimano Ultegra R8000
Cockpit
Stem
3T ARX II Pro Grey, ±6° rise, Ø31.8mm, 43cm: 80mm --- 47 - 51cm: 90mm --- 54 - 56cm: 100mm --- 58cm: 110mm --- 61cm: 120mm
Handlebar
3T Ergosum Pro Grey, 89mm reach, 128mm drop, Ø31.8mm, 43 - 51cm: 400mm* --- 54 - 56cm: 420mm --- 58 - 61cm: 440mm *Note - Ernova Pro Grey for 43 - 51cm size
Grips
Felt VelvetGel tape with 3M reflective base with reflective Felt Bubble-Tech F-Wing bar end plugs
Headset
FSA integrated sealed cartridge bearing with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), Felt top cap, 43 - 47cm: IS-21, 1.125"" --- 51 - 54cm: No.382, 1.125 - 1.25"" --- 56 - 61cm: No.42, 1.125 - 1.5"
Seat
Saddle
Prologo Nago Evo PAS T2.0
Seatpost
Felt UHC Performance carbon fiber, Ø27.2mm x 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.44 mm | 1.46 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 577 mm | 585 mm | 591 mm | 606 mm | 621 mm |
| Rake | 52 mm | 47 mm | 47 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 58 mm | 54 mm | 55 mm | 53 mm | 52 mm |
| Stack | 503 mm | 521 mm | 541 mm | 563 mm | 585 mm | 612 mm |
| Reach | 360 mm | 368 mm | 376 mm | 385 mm | 396 mm | 405 mm |
| Top Tube Length | 503 mm | 521 mm | 539 mm | 554 mm | 574 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 425 mm | 465 mm | 505 mm | 525 mm | 555 mm | 595 mm |
| Head Tube Angle | 71.5 ° | 72.25 ° | 73 ° | 73.5 ° | 73.75 ° | 74 ° |
| Head Tube Length | 100 mm | 115 mm | 135 mm | 155 mm | 177 mm | 205 mm |
| Chainstay Length | 394 mm | 394 mm | 396 mm | 396 mm | 398 mm | 401 mm |
| Wheelbase | 958 mm | 960 mm | 971 mm | 977 mm | 994 mm | 1012 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 667 mm | 701 mm | 738 mm | 758 mm | 781 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
About this model
FR3 completes the Felt Fr3 model. Felt launched 6 bikes of this model so far. You can easily view all of the Felt Fr3 bikes models from 2018, here.
Model range prices
The most economical model, the Felt FR3 2018 has a starting price of 3299$. Felt FR3 DISC 2018 on the other hand is the most expensive at 3799$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2018 and its price was 3299$. Doing a quick comparison, we notice that FR3 price is 1.55% smaller than the average cost of a Race bike.
Average weight for Race bikes
Race bikes have an average weight of 6.82 kg (15.04 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 7.4 kg (16.31 lbs), the FR3 model is a bit heavier than average. In other words, this model is 8.5% heavier than the average Race bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on FR3 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
FR3 comes in 6 sizes, that range from 152 cm – 196 cm (4.99 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
