Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Integrated Aero TT / Tri UHC Performance carbon fiber, MMC with InsideOut construction, BB30 and carbon horizontal dropouts with integrated dropout adjusters, aerodynamically optimized for direct mount rear brake, mechanical (internal) or electronic (internal) cable routings
Suspension Fork
Felt UHC Performance carbon fiber monocoque construction, 1.125" carbon fiber steer, blades, dropouts, crown, aerodynamically optimized for a conventional brake
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2 braze-on
Shift Levers
Shimano TT/Tri Di2, 2 Button
Cassette
Shimano 11-speed, 12-28T
Crank
Vision TriMax Pro TT BB30 48cm = 165mm 51cm = 167.5mm 54 - 56cm = 170mm 58cm = 172.5mm
Bottom Bracket
Vision BB30
Chain
Shimano 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TTR3, sealed cartridge bearing, 24H
Rear Hub
Felt R3, sealed cartridge bearing, 28H, 11-speed
Rims
Felt TTR3, 22mm Width, 35mm Depth
Spokes
1.8 / 1.2 / 1.8mm butted aero stainless steel w/ aluminum nipples
Tires
Felt Aero TTR2, 700c x 23c
Brakes
Brakes
Front Brake: Vision TriMax Aero Caliper/Rear Brake: FSA Aero Direct Mount
Brake Levers
Shimano Ultegra Tri Di2, 2 Button
Cockpit
Stem
Felt Tri155
Handlebar
Felt Bayonet 3 base bar w/ Felt ƒ-Bend 3-position extensions, Ø31.8mm 48 - 54cm = 390mm 56 - 58cm = 420mm
Grips
Felt VelvetGel Tape, Felt Tri Tip Grips & Dimpled Gel Pads
Headset
FSA IS Integrated, 1.125" sealed ACB cartridge bearings w/ Felt compression device
Seat
Saddle
Prologo TGALE TiRox
Seatpost
Felt Vibration Reducing Aero Tri UHC Advanced carbon fiber w/ 3T DiffLock™ Comfort Module internals, 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.23 mm | 1.24 mm | 1.26 mm | 1.26 mm | 1.26 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 570 mm | 591 mm | 601 mm | 626 mm | 652 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 60 mm | 61 mm | 62 mm | 62 mm | 62 mm |
| Stack | 471 mm | 493 mm | 517 mm | 541 mm | 563 mm |
| Reach | 384 mm | 399 mm | 410 mm | 428 mm | 447 mm |
| Top Tube Length | 471 mm | 494 mm | 514 mm | 542 mm | 571 mm |
| Seat Tube Angle | 79.5 ° | 79 ° | 78.5 ° | 78 ° | 77.5 ° |
| Seat Tube Length | 489 mm | 512 mm | 538 mm | 563 mm | 586 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 63 mm | 86 mm | 109 mm | 134 mm | 157 mm |
| Chainstay Length | 404 mm | 404 mm | 404 mm | 404 mm | 404 mm |
| Wheelbase | 962 mm | 984 mm | 994 mm | 1020 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 737 mm | 759 mm | 783 mm | 807 mm | 829 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
IA 10 is part of the Felt Ia model. Felt launched 58 bikes of this model so far. Take a sneak peek at all Felt Ia bikes models from 2017, by clicking here.
Model range prices
The most economical model, the Felt IA 16 2017 has a starting price of 2999$. Felt IA FRD 2017 on the other hand is the most expensive at 16999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Triathlon bikes
According to our calculations, the average cost of a Triathlon bike that is reliable is 4177$. However, this doesn’t mean that if you spend less money on a Triathlon bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2017 for 4999$. Comparing this to the average Triathlon bike price, we see that the price is 19.68% higher.
Average weight for Triathlon bikes
Triathlon bikes have an average weight of 8.9 kg (19.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit heavier than average, IA 10 has a weight of 9.58 kg (21.12 lbs). In conclusion, the average Triathlon bike weighs 7.64% less than IA 10.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on IA 10 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The IA 10 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
