Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2, Vision -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Integrated Aero TT / Tri UHC Ultimate + TeXtreme® carbon fiber, MMC w/ InsideOut construction, BB30 & carbon horizontal dropouts w/ integrated chain tensioners, internal cable routing (mechanical compatible)
Suspension Fork
Felt Dagger UHC Ultimate + TeXtreme® carbon fiber monocoque construction, 1.25" carbon fiber steerer, brake covers, blades, dropouts, crown w/ Felt compression device
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2
Front Derailleur
Shimano Dura-Ace Di2 braze-on
Shift Levers
Shimano Dura-Ace TT Di2
Cassette
Shimano Ultegra 11-speed, 11-25T
Crank
"Vision TriMax Carbon TT BB30 48cm = 165mm 51cm = 170mm 54cm = 172.5mm 56 - 58cm = 175mm"
Bottom Bracket
FSA BB30 w/ 24mm spindle reducers
Chain
Shimano Ultegra 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TTR1, sealed bearing, 18H
Rear Hub
Felt TTR1, sealed bearing, 20H, 11-speed
Rims
Felt TTR1 by Reynolds; carbon, clincher utilizing new DET™ aero technology What is DET™ aero technology?
Spokes
DT Swiss 2.0 / 1.2 / 2.0mm butted stainless steel w/ aluminum spoke nipples
Tires
Felt Aero TTR1, 220tpi, 700 x 23c
Brakes
Brakes
Felt Aero w/ integrated cover
Brake Levers
Shimano Dura-Ace TT Di2
Cockpit
Stem
Felt Dagger
Handlebar
Felt Dagger UHC Ultimate + Nano base bar w/ Felt ƒ-Bend carbon fiber 3-position extensions
Grips
Devox VelvetGel Tape & Dimpled Gel Pads
Headset
FSA IS integrated, 1.125" ceramic sealed cartridge bearing
Seat
Saddle
ISM Attack Ti
Seatpost
Felt Vibration Reducing Aero Tri UHC carbon fiber w/ 3T DiffLock™ Comfort Module internals, 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.27 mm | 1.31 mm | 1.3 mm | 1.29 mm | 1.29 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 572 mm | 589 mm | 602 mm | 630 mm | 659 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 60 mm | 60 mm | 62 mm | 61 mm | 62 mm |
| Stack | 472 mm | 499 mm | 517 mm | 541 mm | 567 mm |
| Reach | 373 mm | 381 mm | 398 mm | 418 mm | 439 mm |
| Top Tube Length | 462 mm | 480 mm | 504 mm | 535 mm | 567 mm |
| Seat Tube Angle | 79.5 ° | 79 ° | 78.5 ° | 78 ° | 77.5 ° |
| Seat Tube Length | 496 mm | 525 mm | 546 mm | 571 mm | 598 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 67.5 mm | 96 mm | 111 mm | 136 mm | 163 mm |
| Chainstay Length | 394 mm | 394 mm | 394 mm | 394 mm | 394 mm |
| Wheelbase | 955 mm | 972 mm | 985 mm | 1014 mm | 1043 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 738 mm | 770 mm | 784 mm | 813 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
IA FRD belongs to the Felt Ia model. Felt launched 58 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
Felt IA FRD 2014 is the most economical model, with a starting price of 9999$. Felt IA FRD LTD 2014 on the other hand costs 13999$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Triathlon bikes
Our math shows that the average cost of a dependable Triathlon bike is 4177$. However, even though the average price of a Triathlon bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2014 and its price was 9999$. Doing a quick comparison, we notice that IA FRD price is 139.38% higher than the average cost of a Triathlon bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the IA FRD bike is equipped with the 700c carbon model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
