Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, microSHIFT -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Integrated Aero TT / Tri UHC Performance carbon fiber, MMC with InsideOut construction, BB30 and carbon horizontal dropouts with integrated chain tensioners, aerodynamically optimized for direct mount rear brake, internal cable routing (mechanical and electronic compatible)
Suspension Fork
Felt UHC Performance carbon fiber monocoque construction, 1.125" carbon fiber steer, blades, dropouts, crown, aerodynamically optimized for a conventional brake
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 short cage
Front Derailleur
Shimano 105 braze-on
Shift Levers
microSHIFT TT 11-speed
Cassette
Shimano 11-speed, 11-28T
Crank
FSA Omega BB30 51cm =165mm 54 - 56cm = 170mm 58 - 60cm = 172.5mm
Bottom Bracket
FSA BB30
Chain
Shimano 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt R3, sealed bearing, 24H
Rear Hub
Felt R3, sealed cartridge bearing, 28H, 11-speed
Rims
Felt TTR4, 22mm Width, 30mm Depth
Spokes
2.0mm stainless steel
Tires
Felt Aero TTR2, 700c x 23c
Brakes
Brakes
Rear-Direct mount caliper, Front-Dual pivot caliper
Brake Levers
Aero TT / Tri
Cockpit
Stem
Felt Tri155
Handlebar
Felt Bayonet 3 base bar with Felt ƒ-Bend 3-position extensions, Ø31.8mm 48 - 54cm = 390mm 56 - 58cm = 420mm
Grips
Felt VelvetGel Tape, Felt Tri Tip Grips and Dimpled Gel Pads
Headset
FSA IS Integrated, 1.125" sealed ACB cartridge bearings with Felt compression device
Seat
Saddle
Prologo Zero Tri PAS T2.0
Seatpost
Felt Vibration Reducing Aero Tri UHC Advanced carbon fiber with 3T DiffLock™ Comfort Module internals, 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.23 mm | 1.24 mm | 1.26 mm | 1.26 mm | 1.26 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 570 mm | 591 mm | 601 mm | 626 mm | 652 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 60 mm | 61 mm | 62 mm | 62 mm | 62 mm |
| Stack | 471 mm | 493 mm | 517 mm | 541 mm | 563 mm |
| Reach | 384 mm | 399 mm | 410 mm | 428 mm | 447 mm |
| Top Tube Length | 471 mm | 494 mm | 514 mm | 542 mm | 571 mm |
| Seat Tube Angle | 79.5 ° | 79 ° | 78.5 ° | 78 ° | 77.5 ° |
| Seat Tube Length | 489 mm | 512 mm | 538 mm | 563 mm | 586 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 63 mm | 86 mm | 109 mm | 134 mm | 157 mm |
| Chainstay Length | 404 mm | 404 mm | 404 mm | 404 mm | 404 mm |
| Wheelbase | 962 mm | 984 mm | 994 mm | 1020 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 737 mm | 759 mm | 783 mm | 807 mm | 829 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
IA16 Black Edition is a Felt Ia16 model. There are 3 bikes that carry this model name. Take a sneak peek at all Felt Ia16 bikes models from 2018, by clicking here.
Model range prices
The most economical model, the Felt IA16 2018 has a starting price of 2999$. Felt IA16 Black Edition 2018 on the other hand is the most expensive at 2999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Triathlon bikes
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, you could also get a good Triathlon bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2999$. Comparing this to the average Triathlon bike price, we see that the price is 39.28% smaller.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
IA16 Black Edition components
Fork material
IA16 Black Edition has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the IA16 Black Edition bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
