Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox
-
Groupset X7, X5 -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Nine Series XC, UHC Performance carbon fiber, InsideOut internally optimized molding process, Modular Monocoque Construction (MMC), full carbon dropouts, ControlTaper head tube, Kevlar chain watcher, replaceable derailleur hanger, internal derailleur cable routing w/IS disc mounts, standard 73mm bottom bracket, 135mm OLD, Ø27.2mm seatpost, 34.9mm high clamp front derailleur
Suspension Fork
RockShox XC32, Solo Air 100mm travel, XC30, 100mm travel, coil, PopLoc remote lockout, adjustable rebound, magnesium lowers, 9mm QR, post style disc mount
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM X7 10-speed long cage
Front Derailleur
SRAM X5 high clamp Ø34.9mm, bottom pull 2 x 10-spee
Shift Levers
SRAM X5 2 x 10-speed
Cassette
SRAM 10-speed 11-36T
Crank
SRAM S1000 2 x 10-speed: XS/SM - 170mm MD/LG/XL - 175mm
Bottom Bracket
GXP
Chain
SRAM 10-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Forged aluminum, 6-bolt disc mount, 32 hole, 9mm QR axle
Rear Hub
Forged aluminum 10-speed, 6-bolt disc mount, 32 hole, 135 x 10mm axle
Rims
WTB SX 17 29" double wall aluminum w/ eyelets
Spokes
Stainless steel 2.0mm w/ aluminum nipples
Tires
WTB Prowler 60TPI folding, 29 x 2.1
Brakes
Brakes
Tektro HDC hydraulic disc w/ 180mm rotor
Brake Levers
Tektro HDC hydraulic
Cockpit
Stem
Felt MTB 3D-forged threadless 1-1/8" +/- 7° rise for Ø31.8mm handlebar w/ CP Cr-Mo bolts: XS - 70mm SM/MD - 80mm LG - 90mm XL - 100mm
Handlebar
Felt MTB flat top double-butted 6061 aluminum, 5mm rise, 9° sweep, 720mm wide
Grips
Felt Wing Grip, Lock-On
Headset
FSA No.42 integrated tapered Aheadset, custom cone spacer 1 x 8mm + 2 x 5mm straight spacers, w/ Felt Tornado aluminum top cap
Seat
Saddle
Felt MTB performance
Seatpost
Felt butted 6061 aluminum w/ 2 bolt micro-adjust 15mm offset: XS/SM - Ø 27.2 x 350mm MD/LG/XL - Ø 27.2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 18" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.55 mm | 1.5 mm | 1.47 mm | 1.42 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 617 mm | 632 mm | 652 mm | 672 mm | 695 mm |
| Rake | 51 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 75 mm | 77 mm | 77 mm | 77 mm | 77 mm |
| Stack | 600 mm | 623 mm | 632 mm | 642 mm | 651 mm |
| Reach | 385 mm | 403 mm | 420 mm | 437 mm | 457 mm |
| Top Tube Length | 567 mm | 592 mm | 612 mm | 632 mm | 652 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1056 mm | 1071 mm | 1091 mm | 1111 mm | 1134 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 686 mm | 721 mm | 767 mm | 801 mm | 830 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Nine 5 completes the Felt Nine model. There are 66 bikes that carry this model name. Take a sneak peek at all Felt Nine bikes models from 2014, by clicking here.
Model range prices
Felt Nine 80 2014 is the cheapest bike model and costs 599$. Felt Nine 1 2014 is the most expensive one and costs 4499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Felt released this model in 2014, its price was 1999$. Comparing this to the average Crosscountry bike price, we see that the price is 4.93% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Nine 5 components
Fork
Felt Nine 5 2014 bike is equipped with the RockShox fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of magnesium, but they are not so popular as steel or carbon forks.
Wheels
When it comes to wheels, the Nine 5 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Felt Nine 5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
