Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset X4, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
15.5"
153cm - 167cm
17.5"
170cm - 184cm
19.5"
176cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FELT Nine alloy Trail series 29'er frame, butted 6061 aluminum: w/ hydroformed top tube, IS disc mounts, oversized integrated head tube for semi-integrated headset, replaceable derailleur hanger
Suspension Fork
SR Suntour SF11-XCT29 100mm travel: 29'er fork, Aluminum bottom case, 28mm CP stanchions, IS mount disc mount
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X-4: Med cage: 8 speed
Front Derailleur
Shimano FD-M310: top swing
Shift Levers
SRAM X-4 triggers: 8 speed
Cassette
Sunrace 8-speed 11-32
Crank
SR Suntour CW10-XCT-V2-T302:-PBG crankset: w/ forged alloy arms 8-speed w/ interchangable 42X32X24T chainrings, lengths 15.5"= 170mm; 17.5/21.5"=175mm
Bottom Bracket
Sealed Cartridge
Chain
KMC Z72 8-speed
Chain Guide
N/A
Pedals
VP 992-S Steel Cage w/ PP Body
Wheels
Front Hub
Forged alloy 6-bolt disc mount: 32 hole, w/ alloy quick release
Rear Hub
Forged alloy 6-bolt disc mount, 8/9 speed cassette: 32 hole, w/ alloy quick release lever
Rims
29'er doublewall aluminum For disc brake
Spokes
Stainless 14g w/ brass nipples
Tires
Geax AKA 2.2 wire bead" witrh Presta valve tubes
Brakes
Brakes
Tektro Novella mechanical disc brake: 160mm front/ 160mm rear stainless steel rotors
Brake Levers
Tektro 2 finger alloy
Cockpit
Stem
Felt MTB 3D-forged design: 4-bolt handlebar clamp, 1-1/8" threadless, for 31.8mm handlebar, 7 degree rise, w/ CP Cromo hardware Sizes; 15.5-17.5=90mm;19.5-21.5=110mm
Handlebar
Felt MTB XC riser bar: butted 6061 Aluminum, 8 degree bend, 4 degree up sweep 31.8mm bar bore, Widths: 15.5""=640mm, 17.5"-21.5"=660mm
Grips
Felt dual-density wing grips: Kraton rubber base, Pruven rubber center, Color matched
Headset
Semi-integrated 1-1/8" Aheadset: Steel Cups, Caged Bearing, w/ Felt Tornado alloy top cap, custom curved 1 x 15mm + 2 x 5mm straight washers
Seat
Saddle
Felt mountain design: low side profile look w/ comfort fit top, double-density base, satin steel rails
Seatpost
Felt alloy micro adjust: 6061 alloy, low-profile forged head & extruded rail clamps, sizes: 15.5"=30.9mm x 350mm , 17.5-21.5" =30.9mm x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 19.5" | 21.5" |
|---|---|---|---|---|
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 631 mm | 645 mm | 660 mm | 674 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 584 mm | 604 mm | 619 mm | 634 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 445 mm | 495 mm | 545 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1056 mm | 1076 mm | 1091 mm | 1106 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 734 mm | 764 mm | 799 mm | 833 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 153 cm | 170 cm | 176 cm | 186 cm |
| Rider Max Height | 167 cm | 184 cm | 189 cm | 196 cm |
Model Overview
Nine Flow completes the Felt Nine model. Felt launched 66 bikes of this model so far. Take a sneak peek at all Felt Nine bikes models from 2012, by clicking here.
Model range prices
Felt Nine Flow 2012 is the most affordable bike of this model and has a price of 599$. On the other hand, Felt Nine Team 2012, is the most expensive and costs 5999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 599$. Comparing the average cost of a Crosscountry bike to this one, you will see that Nine Flow price is 218.03% smaller.
Nine Flow components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The Nine Flow 2012 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Felt Nine Flow is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 153 cm – 196 cm (5.02 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
