Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt FitWoman Road UHC Performance MMC carbon fiber w/ 3KP weave, InsideOut internal molding process, machined threaded aluminum BB shell, external cable routing, forged aluminum dropouts & replaceable rear derailleur hanger
Suspension Fork
Felt UHC Performance fork, carbon fiber steerer tube, crown, blades, & forged aluminum dropouts, 461g
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 SS short cage
Front Derailleur
Shimano 105 braze-on
Shift Levers
Shimano 105 STI
Cassette
Shimano 12-30T
Crank
Shimano R656S Compact, 50/34T; small=165mm, medium=170mm, tall=172.5mm
Bottom Bracket
Shimano Hollowtech-II
Chain
Shimano 10 speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt premium sealed bearing forged aluminum w/ Felt quick release, 28H
Rear Hub
Felt premium sealed bearing forged Shimano 9/10 speed compatible freehub w/ Felt quick release, 28H
Rims
MAVIC CXP-22S aluminum w/ machined UB Control braking surface & wear indicator laced 28H front, 28H rear
Spokes
Swiss 2.0mm stainless steel laced radial front, 3x rear w/ aluminum nipples
Tires
Vittoria Rubino, 700c x 23c
Brakes
Brakes
Dual pivot w/ stainless hardware & cartridge brake pads
Brake Levers
Shimano 105 STI
Cockpit
Stem
Felt FitWoman SL 6061 aluminum 3D forged +/-7° rise, Ø31.8mm bar clamp, custom Cr-Mo bolts, 131g; small=70mm, medium=80mm, tall=90mm
Handlebar
Felt FitWoman VS 6061 aluminum bar w/ Felt Variable Shape ergonomic drop, Ø31.8mm, small & medium=380mm, tall=400mm
Grips
Felt FW Fit Woman soft touch tape
Headset
FSA 1.125"" integrated, w/ aluminum 25mm conical spacer, 2 X 10mm aluminum headset spacers, Felt aluminum top cap & 7075 anodized aluminum bolt
Seat
Saddle
Felt FitWoman VS road saddle w/ nylon injection molded base, superlight multi-density foam, embossed cover, & hollow Cr-Mo rails
Seatpost
Felt FitWoman UHC Performance carbon fiber post, forged aluminum head, lightweight twin side clamp bolt design, Ø27.2mm, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Petite | SM | MD | Tall |
|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.38 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 291 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 561 mm | 584 mm | 584 mm | 595 mm |
| Rake | 40 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 60 mm | 57 mm | 54 mm |
| Stack | 480 mm | 516 mm | 537 mm | 557 mm |
| Reach | 366 mm | 373 mm | 370 mm | 380 mm |
| Top Tube Length | 493 mm | 511 mm | 521 mm | 541 mm |
| Seat Tube Angle | 75.5 ° | 75.3 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 430 mm | 450 mm | 470 mm | 500 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 130 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 396 mm | 413 mm | 413 mm | 413 mm |
| Wheelbase | 952 mm | 987 mm | 987 mm | 998 mm |
| Bottom Bracket Drop | 45 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
ZW5 completes the Felt Zw5 model. Felt launched 8 bikes of this model so far. You can get a glimpse at all models from 2012, by clicking on this link.
Model range prices
Felt ZW5 650 2012 is the cheapest bike model and costs 2299$. Felt ZW5 2012 is the most expensive one and costs 2299$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Felt ZW5 price was 2299$. Doing a quick comparison, we notice that ZW5 price is 45.72% smaller than the average cost of a Race bike.
Race bikes average weight
The average weight for Race bikes is 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 7.74 kg (17.06 lbs), Felt bike is considerably heavier than average. In conclusion, the average Race bike weighs 13.49% less than ZW5.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
ZW5 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the ZW5 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
