Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari R3A compact design, double-butted, heat-treated, light-weight aluminum, *Note: Smaller frames do not support second set of bottle cage bosses
Suspension Fork
Fezzari F1 Carbon Fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 GS, 10 speed
Front Derailleur
Shimano Tiagra 4700, braze-on, 2 speed, new longer actuation arm for smoother easier shifting
Shift Levers
Shimano Tiagra 4700 Dual Control, 2x10 speed
Cassette
Shimano Tiagra 4700 HG500, 10 speed, 11x34t, extra wide range for easier hill climbing without sacrificing high gear
Crank
FSA Omega Compact MegaExo, anodized black
Bottom Bracket
FSA MegaExo English thread with oversize external cartridge bearings (integrated), heavy duty
Chain
KMC X10 NP/GY, 10 speed
Pedals
Wellgo C127 Platform
Wheels
Front Hub
Formula, alloy, 28 hole
Rear Hub
Formula, alloy, 28 hole
Rims
Alex AT-470, 700c, alloy double wall, CNC machined sidewalls, 28-hole, Tubeless Ready
Spokes
2.0mm (14g) stainless
Tires
Maxxis Detonator, 700x25c
Brakes
Brakes
Tektro R540 Dual Pivot Caliper Brake
Brake Levers
Shimano Tiagra 4700 Dual Control with STI precision, improved comfortable anatomic design, reach adjust
Cockpit
Stem
Fezzari 3D forged 7500 series alloy, 31.8mm 4-bolt bar clamp (rise and length customizable through 23-Point Custom Setup)
Handlebar
Fezzari alloy, double butted 31.8mm, blast black (width customizable through 23-Point Custom Setup)
Headset
FSA 1 1/8” integrated threadless, with triple sealed cartridge bearings, alloy cone & headset spacers
Seat
Saddle
Fezzari Ultra XR fully adjustable, microfiber, ergonomically designed, with embossed logo
Seatpost
Fezzari Racing Design XrT Dual Bolt Carbon, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Top Tube Length | 525 mm | 550 mm | 570 mm | 585 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 480 mm | 500 mm | 525 mm | 550 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 73 ° | 73 ° |
| Chainstay Length | 403 mm | 403 mm | 403 mm | 403 mm |
| Wheelbase | 971 mm | 992 mm | 1007 mm | 1017 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 704 mm | 742 mm | 780 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Catania completes the Fezzari Catania model. Fezzari released 4 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Fezzari Catania 2019 is the most economical model, with a starting price of 999$. Fezzari Catania Disc 2019 on the other hand costs 1199$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 999$. In conclusion, this bike price is 134.83% lower than the price of the average Endurance bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Catania are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Catania comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Fezzari Catania bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
