Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Groupset SX Eagle, X1 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Racing Design Fat King Carbon V3, full carbon construction, 197x12mm rear axle, 100mm english thread BB, tapered headtube, internal cable routing
Suspension Fork
Fezzari Racing Design Kings Peak Carbon V3, tapered, 150x15mm thru axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle, 1x12
Cassette
SRAM CS-PG1210 SX Eagle 11-50t
Crank
SRAM X1 1000 Eagle DUB, for Fat Bike
Bottom Bracket
SRAM DUB BSA 100
Chain
SRAM SX Eagle 12-Speed
Pedals
Available Separately
Wheels
Front Hub
Bear Pawls Alloy F: 15x150mm, Sealed Cartridge Bearing, 6 bolt disc Rear: Bear Pawls R: 12x197mm, Sealed Cartridge Bearings
Rear Hub
Bear Pawls Alloy F: 15x150mm, Sealed Cartridge Bearing, 6 bolt disc Rear: Bear Pawls R: 12x197mm, Sealed Cartridge Bearings
Rims
Sun Ringle Mulefut SL 80mm, 32 hole. Carbon Wheel Upgrade Available At Checkout.
Spokes
Wheelsmith DB14
Tires
Terrene Cake Eater 27.5x4.5 Tubeless Ready
Brakes
Brakes
Clarks M2 Hydraulic 160/160mm Rotors
Brake Levers
Clarks M2 Hydraulic
Cockpit
Stem
Fezzari Alloy, 31.8mm (Size varies with 23-point custom setup)
Handlebar
Fezzari Racing Design Alloy Flat Bar, 31.8mm x 780 mm (customized sizing through 23-Point Custom Setup)
Headset
FSA integrated sealed cartridge bearing, tapered, No. 42ACB
Seat
Saddle
Selle Italia Model X Superflow
Seatpost
Fezzari Racing Design XrT Dual Bolt alloy, 31.6 Diameter, Dropper seatpost available after adding bike to cart
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.391 mm | 1.367 mm | 1.33 mm | 1.296 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm | 325 mm |
| Front Center | 715 mm | 742 mm | 766 mm | 790 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 119 mm | 119 mm | 119 mm | 119 mm |
| Stack | 598 mm | 615 mm | 625 mm | 635 mm |
| Reach | 430 mm | 450 mm | 470 mm | 490 mm |
| Top Tube Length | 590 mm | 614 mm | 637 mm | 660 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 440 mm | 460 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1156 mm | 1184 mm | 1208 mm | 1232 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 700 | 750 mm | 770 mm | 780 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Kings Peak Comp belongs to the Fezzari Kings model. Fezzari released 11 bikes variations of this model so far. Take a sneak peek at all Fezzari Kings bikes models from 2022, by clicking here.
Model range prices
Fezzari Kings Peak Comp 2022 is the cheapest bike model and costs 2399$. Fezzari Kings Peak Elite 2022 is the most expensive one and costs 2899$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Fatbike bikes
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, even if your budget is less than the average, you might still be able to get a top-quality Fatbike bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Fezzari released this model in 2022, its price was 2399$. Doing a quick comparison, we notice that Kings Peak Comp price is 37.64% higher than the average cost of a Fatbike bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Kings Peak Comp components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Kings Peak Comp are the 27.5″ carbon type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fezzari Kings Peak Comp has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Kings Peak Comp comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
