Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Shafer Gravel Frameset - compact design, double-butted, heat-treated, light-weight aluminum, *Note: Smaller frames do not support second set of bottle cage bosses 10x135 QR rear 12x100 front thru axles. Frame Defense Tech derailleur hanger. Max tire clearance 40c.
Suspension Fork
Fezzari Gravel Carbon Disc Fork, 12x100 Thru Axle, 40c tire clearance, 1 1/8-1.5 taper, internal routing
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Apex 1x11
Front Derailleur
N/A
Shift Levers
SRAM Apex 1x11 Hydraulic
Cassette
SRAM PG1130, 11-42T
Crank
SRAM Apex 1, GXP, 1x11, Alloy
Bottom Bracket
SRAM GXP English BSA
Chain
SRAM PC-1110 11-spd
Pedals
Available Separately
Wheels
Front Hub
Bear Pawls Road Disc
Rear Hub
Bear Pawls Road Disc
Rims
Alex GD24, Tubeless Ready
Spokes
15G Stainless Steel, J-Pull
Tires
Maxxis Receptor 40c EXO Tubeless Ready
Brakes
Brakes
SRAM Apex, hydraulic disc, SRAM Centerline 160mm Rotors
Brake Levers
SRAM Apex Hydraulic Disc
Cockpit
Stem
Fezzari 3D forged 31.8mm alloy, 7 degree, 4-bolt bar clamp (customized sizing through 23-Point Custom Setup)
Handlebar
Fezzari GR Alloy. 31.8 diameter, 70mm reach, 120mm drop, 18 degree flare
Headset
FSA Orbit 1.5 ZS NO.57E
Seat
Saddle
Selle Italia Model X Superflow
Seatpost
Fezzari Racing Design XrT Carbon, Dual bolt adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.45 mm | 1.5 mm | 1.52 mm | 1.58 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 614 mm | 629 mm | 646 mm | 660 mm | 671 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Stack | 519 mm | 548.7 mm | 578.4 mm | 597.7 mm | 624 mm |
| Reach | 372 mm | 378.7 mm | 384.5 mm | 393 mm | 394.5 mm |
| Top Tube Length | 508.4 mm | 525.4 mm | 552.3 mm | 572 mm | 587.4 mm |
| Seat Tube Angle | 75.5 ° | 75.2 ° | 74 ° | 73.5 ° | 73.1 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 492 mm | 520 mm |
| Head Tube Angle | 68.9 ° | 68.9 ° | 68.9 ° | 68.9 ° | 68.9 ° |
| Head Tube Length | 93.7 mm | 125.8 mm | 158 mm | 178 mm | 206.1 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1025 mm | 1040 mm | 1057 mm | 1072 mm | 1083 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 77 mm | 77 mm | 77 mm |
| Standover Height | 692 mm | 723 mm | 753 mm | 781 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Shafer AL completes the Fezzari Shafer model. There are 20 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Fezzari Shafer AL 2023 is the most economical model, with a starting price of 1899$. Fezzari Shafer Pro Force XX Transmission 2023 on the other hand costs 4799$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2023 and its price was 1899$. Comparing this to the average Gravel bike price, we see that the price is 29.65% lower.
Shafer AL components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Shafer AL are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Shafer AL has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Fezzari Shafer AL bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
