Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 170mm -
Fork RockShox ZEB Ultimate
-
Groupset X0 Eagle Transmission, SRAM -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano EP8 250W, 85 nm torque motor, 635 Wh removable battery -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Timp Peak CleanCast™ Carbon TetraLink™ Full Suspension, 170mm travel
Suspension Fork
Rockshox ZEB Ultimate RC2, Charger 3 Buttercups, 170mm travel, 15x110 Axle, 42mm offset, tapered steerer
Rear Shock
RockShox Super Deluxe Ultimate RC2T, 230x65, Custom Tuned
Drivetrain
Rear Derailleur
SRAM XO Eagle Transmission 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM XS-1295 XO Eagle, 10-52t, 12-speed
Crank
Shimano EM600, 160mm
Bottom Bracket
Shimano EP8 motor system
Chain
SRAM XO Eagle Transmission Flattop 12-speed
Chain Guide
MRP 1x for EP8. Drive
Pedals
Available Separately
Wheels
Front Hub
F: DT Swiss 350, Disc, 15x110 thru axle, R: DT Swiss 350 Ratchet System, Disc, 12x148 thru axle, XD
Rear Hub
F: DT Swiss 350, Disc, 15x110 thru axle, R: DT Swiss 350 Ratchet System, Disc, 12x148 thru axle, XD
Rims
DT Swiss HX1700, 29, Tubeless ready
Spokes
DT hybrid 3 straightpull
Tires
F: Maxxis Assegai 29x2.5WT, EXO+, 3C, TR Protection, Tubeless Ready. R: DH-R 29x2.4WT, EXO+, 3C, TR Protection, Tubeless Ready
Brakes
Brakes
TRP DH-R EVO, 2.3mm 203/203mm
Cockpit
Stem
Fezzari FRD Charger35, alloy, 35mm clamp, sizes vary depending on 23-Point Custom Setup™ selections
Handlebar
Fezzari team 35mm bar-customized sizing through 23-Point Custom Setup™
Headset
Cane Creek 40 Series ZS56/ZS56
Seat
Saddle
Selle Italia Model X Superflow Comfort
Seatpost
PNW Loam Dropper & Puget Lever (Travel adjusted with 23-Point Custom Setup™ selections after checkout)
Motor & Battery
Motor
Shimano EP8 250W, 85 nm torque motor, 635 Wh removable battery
Battery
Shimano EP8 250W, 85 nm torque motor, 635 Wh removable battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.408 mm | 1.366 mm | 1.3 mm | 1.254 mm |
| Bottom Bracket Height | 347.6 mm | 347.6 mm | 347.6 mm | 347.6 mm |
| Front Center | 770 mm | 795 mm | 829 mm | 858 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 144 mm | 144 mm | 144 mm | 144 mm |
| Stack | 612.6 mm | 621.6 mm | 630.6 mm | 639.5 mm |
| Reach | 435 mm | 455 mm | 485 mm | 510 mm |
| Top Tube Length | 568.1 mm | 584.9 mm | 613.1 mm | 637.2 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 440 mm | 460 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1206 mm | 1230 mm | 1264 mm | 1294 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm | 26 mm |
| Standover Height | 739 mm | 741 mm | 742 mm | 744 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Timp Peak Pro XO Transmission belongs to the Fezzari E Timp model. 8 e-bikes variations carry this model name so far. You can easily view all of the Fezzari E Timp e-bikes models from 2023, here.
Model range prices
Fezzari Timp Peak Comp 2023 is the most economical model, with a starting price of 5999$. Fezzari Timp Peak Team 2023 on the other hand costs 9999$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The fork installed on this bike is the RockShox ZEB Ultimate model. The travel on this model is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this e-bike has the RockShox Super Deluxe Ultimate RC2T model, with a travel of 170mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Fezzari Timp Peak Pro XO Transmission 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Timp Peak Pro XO Transmission comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Fezzari Timp Peak Pro XO Transmission includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
