Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 170mm -
Fork Fox Factory Float 38
-
Groupset XX Eagle Transmission, SRAM -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano EP8 250W, 85 nm torque motor, 635 Wh removable battery -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Timp Peak CleanCast™ Carbon TetraLink™ Full Suspension, 170mm travel
Suspension Fork
Fox Float 38, Grip 2 Factory 170mm 44mm offset
Rear Shock
Fox float X2 Factory, 230x65, Custom Tuned
Drivetrain
Rear Derailleur
SRAM XX Eagle Transmission 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM XS-1297 XX Eagle, 10-52t, 12-speed
Crank
Shimano EM600, 160mm
Bottom Bracket
Shimano EP8 motor system
Chain
SRAM XX Eagle Transmission Flattop 12-Speed
Chain Guide
MRP 1x for EP8. Drive
Pedals
Available Separately
Wheels
Front Hub
F: Crankbrothes Synthesis Standard Disc, 15x110 thru axle, R: Crankbrothes Synthesis Standard Disc, 12x148 thru axle, XD
Rear Hub
F: Crankbrothes Synthesis Standard Disc, 15x110 thru axle, R: Crankbrothes Synthesis Standard Disc, 12x148 thru axle, XD
Rims
Crankbrothers Synthesis E-MTB Carbon, 29, F: 28 Hole, R: 32 Hole, Tubeless ready
Spokes
F: Sapim E-Light, R: Sapim Strong
Tires
F: Maxxis Assegai 29x2.5WT, EXO+, 3C, TR Protection, Tubeless Ready. R: DH-R 29x2.4WT, EXO+, 3C, TR Protection, Tubeless Ready
Brakes
Brakes
SRAM CODE Ultimate Stealth, HS2 220/200mm F/R rotors
Cockpit
Stem
Fezzari FRD Charger35, alloy, 35mm clamp, sizes vary depending on 23-Point Custom Setup™ selections
Handlebar
OneUp Carbon E-Bar 35mm, bar-customized sizing through 23-Point Custom Setup™
Headset
Cane Creek 40 Series ZS56/ZS56
Seat
Saddle
Ergon SM10
Seatpost
Fox Transfer Factory Dropper, customized sizing through 23-Point Custom Setup™ selections after checkout)
Motor & Battery
Motor
Shimano EP8 250W, 85 nm torque motor, 635 Wh removable battery
Battery
Shimano EP8 250W, 85 nm torque motor, 635 Wh removable battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.408 mm | 1.366 mm | 1.3 mm | 1.254 mm |
| Bottom Bracket Height | 347.6 mm | 347.6 mm | 347.6 mm | 347.6 mm |
| Front Center | 770 mm | 795 mm | 829 mm | 858 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 144 mm | 144 mm | 144 mm | 144 mm |
| Stack | 612.6 mm | 621.6 mm | 630.6 mm | 639.5 mm |
| Reach | 435 mm | 455 mm | 485 mm | 510 mm |
| Top Tube Length | 568.1 mm | 584.9 mm | 613.1 mm | 637.2 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 440 mm | 460 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1206 mm | 1230 mm | 1264 mm | 1294 mm |
| Bottom Bracket Drop | 26 mm | 26 mm | 26 mm | 26 mm |
| Standover Height | 739 mm | 741 mm | 742 mm | 744 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Timp Peak Team XX Transmission is part of the Fezzari E Timp model. There are 8 e-bikes that carry this model name. You can easily view all of the Fezzari E Timp e-bikes models from 2023, here.
Model range prices
Fezzari Timp Peak Comp 2023 is the most affordable e-bike of this model and has a price of 5999$. On the other hand, Fezzari Timp Peak Team 2023, is the most expensive and costs 9999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Timp Peak Team XX Transmission components
Fork
The Timp Peak Team XX Transmission comes factory-installed with the Fox Factory Float 38 fork. This has a travel range of 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox float X2 Factory rear shock model, which has a travel of 170mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Fezzari Timp Peak Team XX Transmission 2023, has a 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Timp Peak Team XX Transmission comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Timp Peak Team XX Transmission. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
