Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Racing Design Wasatch Peak frame, hydroformed doubled-butted 6061 aluminum tubing, 148x12 dropout, Internal cable routing, internal dropper post routing,replaceable derailleur hanger, water bottle bosses
Suspension Fork
SR Suntour XCR 34 Air LOR DS, 29er/27.5 plus, 120mm travel, Lockout, Rebound Adjust, Boost 110x15 Thru Axle, Tapered Steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle 12 Speed
Cassette
SRAM PG-1210, 11-50t, 12-Speed
Crank
SRAM SX Eagle Crankset 12-Speed Power Spline Spindle Interface
Bottom Bracket
SRAM Power Spline 118/73
Chain
SRAM SX Eagle 12-Speed
Pedals
Available Separately
Wheels
Front Hub
Bear Pawls Sealed Bearing Front: Boost 110x15 thru axle, Rear: Boost 148x12mm thru Axle, HG
Rear Hub
Bear Pawls Sealed Bearing Front: Boost 110x15 thru axle, Rear: Boost 148x12mm thru Axle, HG
Rims
WTB STP i35 27.5, TCS Tubeless Ready, 32h
Spokes
1.8mm (15g) black stainless, brass nipples
Tires
Kenda Havok Pro 27.5x2.8, Tubeless Ready, dual tread compound, sidewall protection
Brakes
Brakes
Tektro HD-M276 Hydraulic Disc 180/160mm Rotor
Brake Levers
Tektro HD-M276 Hydraulic
Cockpit
Stem
Fezzari 3D forged 31.8mm alloy, 7 degree, 4-bolt bar clamp (customized sizing through 23-Point Custom Setup)
Handlebar
Fezzari Racing Design Alloy, 20mm rise, 9 degree back seep, 5 degree upsweep, 31.8mm x 760-780 mm (customized sizing through 23-Point Custom Setup)
Headset
FSA No 57 ZS
Seat
Saddle
Selle Italia Model X
Seatpost
Fezzari alloy, blast black, 31.6 x 350-400 (based on custom setup), Dropper seatpost available after adding bike to cart
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.42 mm | 1.39 mm |
| Bottom Bracket Height | 303.5 mm | 303.5 mm | 303.5 mm | 303.5 mm |
| Front Center | 675 mm | 698 mm | 727 mm | 753 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 90 mm | 90 mm | 90 mm | 90 mm |
| Stack | 611.2 mm | 611 mm | 625 mm | 639 mm |
| Reach | 393 mm | 416 mm | 439 mm | 460 mm |
| Top Tube Length | 557 mm | 580 mm | 607 mm | 632 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 381 mm | 430 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 95 mm | 110 mm | 125 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1101 mm | 1124 mm | 1153 mm | 1179 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 761 mm | 768 mm | 772 mm | 776 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Wasatch Peak Comp 27.5+ is part of the Fezzari Wasatch model. 32 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Fezzari Wasatch Peak Comp 27.5 Plus 2022 is the most economical model, with a starting price of 1199$. Fezzari Wasatch Peak Elite 2022 on the other hand costs 1599$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Wasatch Peak Comp 27.5+ components
Fork
The Suntour XCR Air is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Wasatch Peak Comp 27.5+ 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fezzari Wasatch Peak Comp 27.5+ has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
