flyer Uproc X 9.50 High 2023
2023 E-bike
Estimate price |
12,959$
Weight | 26 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle AXS -
Suspension Full -
Motor Panasonic 95Nm mid-drive -
Battery FLYER FIB-750 36V FIT (750 Wh / 20.1 Ah / 36 V) -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
XL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FLYER Engineered, Hydroformed Tubing, 4-Link Suspension, 150 mm Travel
Suspension Fork
Fox 36 Float Factory E-Optimized, 150 mm travel, 15 x 110 mm Boost
Rear Shock
Fox Float X Factory, 230 x 60 mm
Drivetrain
Rear Derailleur
SRAM X01 AXS, 12 Speed, 10-50t
Cassette
SRAM X01 AXS, 12 Speed, 10-50t
Pedals
VP 532
Wheels
Front Hub
MAVIC E-Deemax S
Rear Hub
MAVIC E-Deemax S
Rims
MAVIC E-Deemax S
Tires
Front: Onza Porcupine TRC 29 x 2.40 (61-622) / Rear: Onza Porcupine GRC 27.5 x 2.60 (66-584)
Brakes
Brakes
Shimano XTR BR-M9120, 203/203 mm
Cockpit
Stem
Satori Ursa, 35 x 35 mm, 0°
Handlebar
Hayes ProTaper Carbon, 810 mm, 8°, 25mm
Seat
Saddle
Fizik Aidon
Seatpost
SRAM Reverb AXS, 125 (S) / 150 (M) / 170 (L-XL) mm Travel, 34.9 mm
Motor & Battery
Motor
Panasonic GX Ultimate Pro FIT (95 Nm)
Battery
FLYER FIB-750 36V FIT (750 Wh / 20.1 Ah / 36 V)
Charger
FIT Fast Charger 36V 6A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.407 mm | 1.398 mm | 1.334 mm | 1.313 mm |
| Bottom Bracket Height | 351 mm | 351 mm | 351 mm | 351 mm |
| Front Center | 763 mm | 771 mm | 803 mm | 833 mm |
| Rake | 45 mm | 45 mm | 45 mm | 44 mm |
| Trail | 129 mm | 125 mm | 125 mm | 126 mm |
| Stack | 612 mm | 622 mm | 631 mm | 650 |
| Reach | 435 mm | 445 mm | 473 mm | 495 mm |
| Top Tube Length | 576 mm | 589 mm | 619 mm | 645 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 400 mm | 415 mm | 450 mm | 485 mm |
| Head Tube Angle | 64.5 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1221 mm | 1229 mm | 1261 mm | 1291 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm | 31 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 195 cm |
Model Overview
Uproc X 9.50 High is part of the Flyer E Uproc model. There are 8 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Flyer Uproc X 2.10 High 2023 has a starting price of 5308$. Flyer Uproc EVO:X 9.50 High 2023 on the other hand is the most expensive at 13271$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
This e-bike was released in 2023 and its price was 11997$. In conclusion, this e-bike price is 150.72% more expensive than the price of the average Enduro e-bike.
Enduro e-bikes average weight
Enduro e-bikes have an average weight of 23.42 kg (51.63 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Flyer Uproc X 9.50 High it’s weighing 26 kg (57.32 lbs). At this weight, is considerably heavier than average. In other words, this model is 11.02% heavier than the average Enduro e-bike.
Overview of components
Fork
Flyer Uproc X 9.50 High 2023 e-bike is equipped with the Fox Factory Float 36 fork, and has 150mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Uproc X 9.50 High has a rear shock with a travel of 150mm. The model Fox Float X Factory is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Uproc X 9.50 High e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Flyer Uproc X 9.50 High is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Uproc X 9.50 High comes in 4 sizes, that range from 155 cm – 195 cm (5.09 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Flyer model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
