flyer Upstreet 5.10 Low 2023
2023 E-bike
Estimate price |
5,583$
Weight | 32 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork Suntour MOBIE
-
Groupset Alivio -
Suspension Hardtail -
Motor Panasonic 95Nm mid-drive -
Battery FLYER FIB-630 36V FIT (630 Wh / 17.75 Ah / 36 V) -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
XL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FLYER Engineered, Hydroformed Tubing
Suspension Fork
SR Suntour MobiE A32 Coil, 75 mm, 15 x 100 mm Axle
Drivetrain
Rear Derailleur
Shimano Alivio, 9 Speed, 11-36t
Cassette
Shimano Alivio, 9 Speed, 11-36t
Pedals
FLYER Wellgo
Wheels
Front Hub
Shimano Alivio HB-MT400, 32h // Formula CL-71, 32h
Rear Hub
Shimano Alivio FH-M4050, 32h // Formula CL-26, 32h
Rims
Alexrims MD30
Tires
Schwalbe Al Grounder 29 x 2.35 (60-622)
Brakes
Brakes
Shimano MT402, 180/180 mm
Cockpit
Stem
FLYER ONE CI Stem, 31.8 x 95 mm
Handlebar
Humpert Ergo XL, 700 mm, 16°, 30 mm
Seat
Saddle
Selle Royal Nuvola
Seatpost
FLYER Alloy, 30.9 mm x 300 (S) / 350 (M-XL) mm
Motor & Battery
Motor
Panasonic GX Ultimate Pro FIT (95 Nm)
Battery
FLYER FIB-630 36V FIT (630 Wh / 17.75 Ah / 36 V)
Charger
FLYER Charger 4A 36V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.72 mm | 1.64 mm | 1.6 mm | 1.57 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 677 mm | 696 mm | 716 mm | 743 mm |
| Rake | 44 mm | 44 mm | 44 mm | 43 mm |
| Trail | 90 mm | 90 mm | 87 mm | 88 mm |
| Stack | 664 mm | 664 mm | 681 mm | 700 |
| Reach | 386 mm | 406 mm | 426 mm | 446 mm |
| Top Tube Length | 590 mm | 610 mm | 635 mm | 661 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm | 600 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 69 ° | 69 ° |
| Head Tube Length | 165 mm | 165 mm | 180 mm | 200 mm |
| Chainstay Length | 498 mm | 498 mm | 498 mm | 498 mm |
| Wheelbase | 1166 mm | 1186 mm | 1206 mm | 1233 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 195 cm |
Model Overview
Upstreet 5.10 Low is a Flyer E Upstreet model. There are 30 e-bikes that carry this model name. Take a sneak peek at all Flyer E Upstreet e-bikes models from 2023, by clicking here.
Model range prices
Flyer Upstreet SL 3.12 XC Medium 2023 is the most affordable e-bike of this model and has a price of 4246$. On the other hand, Flyer Upstreet 7.23 HS High 2023, is the most expensive and costs 7113$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Commuter e-bikes average price
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
This e-bike was released in 2023 and its price was 5096$. If we compare this with the average Commuter e-bike cost we notice that the price is 98.37% more expensive.
Commuter e-bikes average weight
If we make a quick analysis of the average weight of a Commuter e-bike, we get 25.2 kg (55.56 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Flyer Upstreet 5.10 Low it’s weighing 32 kg (70.55 lbs). At this weight, is much heavier than average. To sum up, it’s 26.98% heavier than the average weight of Commuter e-bikes.
Overview of components
Fork
Flyer Upstreet 5.10 Low 2023 e-bike is equipped with the Suntour MOBIE fork, and has 75mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the Upstreet 5.10 Low e-bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Upstreet 5.10 Low has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Flyer Upstreet 5.10 Low e-bike has 4 sizes, in the range of 155 cm – 195 cm (5.09 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
