flyer Upstreet 7.23 HS Low 2023
2023 E-bike
Estimate price |
7,793$
Weight | 32 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Panasonic 95Nm mid-drive -
Battery FLYER FIB-630 36V FIT (630 Wh / 17.75 Ah / 36 V) (S) / FIB-750 (750 Wh / 20.1 Ah / 36 V) (M-XL); Range Extender ready -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
XL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FLYER Engineered, Hydroformed Tubing
Suspension Fork
SR Suntour Mobie25 Coil, 75 mm travel, 15 x 100 mm Axle
Drivetrain
Cassette
Enviolo TR Mech; Gates Carbon Drive CDX
Pedals
FLYER Wellgo
Wheels
Front Hub
Formula DC-71, 32h
Rear Hub
Enviolo TR CVP, 32h
Rims
Alexrims MD30
Tires
Schwalbe Al Grounder 29 x 2.35 (60-622)
Brakes
Brakes
TRP C2.3 203/180 mm
Cockpit
Stem
FLYER ONE CI Stem, 31.8 x 95 mm
Handlebar
Humpert Ergo XL, 700 mm, 16°, 30 mm
Seat
Saddle
Selle Royal Essenza+ Moderate Eco
Seatpost
Satori Xopic2 Suspension, 31.6 x 300 (S) / 350 (M) / 400 (L-XL)
Motor & Battery
Motor
Panasonic GX Ultimate Pro HS FIT (95 Nm)
Battery
FLYER FIB-630 36V FIT (630 Wh / 17.75 Ah / 36 V) (S) / FIB-750 (750 Wh / 20.1 Ah / 36 V) (M-XL); Range Extender ready
Charger
FIT Fast Charger 36V 6A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.72 mm | 1.64 mm | 1.6 mm | 1.57 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 677 mm | 696 mm | 716 mm | 743 mm |
| Rake | 44 mm | 44 mm | 44 mm | 43 mm |
| Trail | 90 mm | 90 mm | 87 mm | 88 mm |
| Stack | 664 mm | 664 mm | 681 mm | 700 |
| Reach | 386 mm | 406 mm | 426 mm | 446 mm |
| Top Tube Length | 590 mm | 610 mm | 635 mm | 661 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 480 mm | 530 mm | 600 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 69 ° | 69 ° |
| Head Tube Length | 165 mm | 165 mm | 180 mm | 200 mm |
| Chainstay Length | 498 mm | 498 mm | 498 mm | 498 mm |
| Wheelbase | 1166 mm | 1186 mm | 1206 mm | 1233 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 195 cm |
Model Overview
Upstreet 7.23 HS Low belongs to the Flyer E Upstreet model. Flyer released 30 e-bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Flyer Upstreet SL 3.12 XC Medium 2023 is the cheapest e-bike model and costs 4246$. Flyer Upstreet 7.23 HS High 2023 is the most expensive one and costs 7113$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Flyer Upstreet 7.23 HS Low price was 7113$. Comparing the average cost of a Commuter e-bike to this one, you will see that Upstreet 7.23 HS Low price is 176.88% higher.
Average weight for Commuter e-bikes
On a deeper look, we notice that the average weight of a Commuter e-bike is 25.2 kg (55.56 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Flyer Upstreet 7.23 HS Low it’s weighing 32 kg (70.55 lbs). At this weight, is much heavier than average. In conclusion, the average Commuter e-bike weighs 26.98% less than Upstreet 7.23 HS Low.
Overview of components
Fork
Flyer Upstreet 7.23 HS Low 2023 e-bike is equipped with the Suntour MOBIE fork, and has 75mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Flyer Upstreet 7.23 HS Low 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Flyer Upstreet 7.23 HS Low has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 155 cm – 195 cm (5.09 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
