Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Arriba, aluminium 6061, disc, BSA BB, 135 mm quick release dropouts, post mount 160 mm, internal brake & gear cable routing
Suspension Fork
Arriba, aluminium, disc, 100 mm quick release, post mount 160 mm, external brake cable routing
Drivetrain
Rear Derailleur
Shimano Claris 2000, 8-speed, short cage
Shift Levers
Shimano Claris SL2000
Bottom Bracket
BSA, threaded
Wheels
Tires
Continental Sport Contact, 700x28C
Brakes
Brakes
Shimano M315, disc, 160 mm / 160 mm
Cockpit
Stem
Concept, aluminium, 31.8mm, +/- 6degree
Handlebar
Concept EX, aluminium, flat
Seat
Seatpost
Concept, aluminium, 27,2 mm, 350 mm, set-back: 15mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.45 mm | 1.44 mm |
| Front Center | 621 mm | 636 mm | 650 | 664 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 76 mm | 75 mm | 75 mm | 75 mm |
| Stack | 567 mm | 581 mm | 595 mm | 605 mm |
| Reach | 389 mm | 399 mm | 409 mm | 419 mm |
| Top Tube Length | 568 mm | 583 mm | 597 mm | 611 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 155 mm | 170 mm | 185 mm | 185 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1046 mm | 1062 mm | 1076 mm | 1090 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
ARRIBA Claris Equipped belongs to the Focus Arriba model. 10 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
ARRIBA Claris Equipped components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The ARRIBA Claris Equipped 2018 bike is equipped with 700c wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Focus ARRIBA Claris Equipped is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
