Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery 500 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminium, internal cable routing, international disc brake standard
Suspension Fork
SR Suntour NEX RL, 9 mm QR, 63 mm travel
Drivetrain
Rear Derailleur
Shimano Deore XT 786, 10-speed
Shift Levers
Shimano Deore M6000
Bottom Bracket
BSA, threaded
Wheels
Rims
Schürmann Yak19 622-19, Shimano TX50 CL, 9 mm, QR
Tires
Schwalbe Delta Cruiser 700x40c Plus
Brakes
Brakes
Shimano M315, 180 mm / 160 mm
Cockpit
Stem
aluminium, 31,8 mm, 90 mm
Handlebar
aluminium, riserbar, 700mm
Seat
Seatpost
Sport components SP-DC1
Motor & Battery
Motor
Bosch Performance CX, 75 Nm, 250 W, 50-300% support power
Battery
500 Wh
Remote
BOSCH INTUVIA
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.53 mm | 1.6 mm | 1.74 mm |
| Front Center | 624 mm | 645 mm | 651 mm | 659 mm |
| Rake | 45 mm | 55 mm | 55 mm | 55 mm |
| Trail | 73 mm | 66 mm | 64 mm | 64 mm |
| Stack | 624 mm | 608 mm | 637 mm | 684 mm |
| Reach | 378 mm | 398 mm | 399 mm | 393 mm |
| Top Tube Length | 569 mm | 579 mm | 594 mm | 609 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 150 mm | 135 mm | 170 mm | 220 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1091 mm | 1112 mm | 1119 mm | 1128 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AVENTURA² Pro is a Focus E Aventura model. There are 18 e-bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid e-bikes average price
Our math shows that the average cost of a dependable Hybrid e-bike is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
AVENTURA² Pro components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the AVENTURA² Pro model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
AVENTURA² Pro comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
