Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MAX technology carbon, disc, BB86, 142x12 mm thru axle, R.A.T Evo technology, Di2/mechanical, flat mount 160 mm, internal cable routing
Suspension Fork
MAX technology carbon, integrated, disc, 100x12 mm, thru axle, R.A.T Evo Technology, flat mount 160/140 mm, internal brake cable routing
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano 105 R7025
Cassette
Shimano 105
Crank
Shimano 105 R7000, 50/34T
Bottom Bracket
Shimano Pressfit Road BB86
Chain
Shimano CN-HG601
Wheels
Rims
Alex Rims CF45 Disc, centerlock, carbon, 100x12/142x12 mm, 24/24 spokes, 19 mm inner width, 45 mm rim height
Tires
Vittoria Rubino TLR, 700 x 25C, Folding
Brakes
Brakes
Shimano 105 R7025 hydraulic disc
Brake Levers
Shimano BRM7020
Cockpit
Stem
BBB Deluxe, aluminium, 31.8mm, +/- 7 degree
Handlebar
BBB Deluxe, aluminium, drop: 125mm, reach: 70mm
Grips
FOCUS Bartape SL
Headset
Acros, IS 52/40-IS52/42
Seat
Saddle
Prologo Scratch
Seatpost
FOCUS IZALCO MAX aero carbon, D-shape, 350 mm, set-back: 15mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.38 mm | 1.4 mm | 1.4 mm | 1.39 mm | 1.42 mm | 1.46 mm |
| Bottom Bracket Height | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm |
| Front Center | 578 mm | 578 mm | 588 mm | 600 mm | 612 mm | 626 mm | 646 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 71 mm | 66 mm | 59 mm | 57 mm | 57 mm | 52 mm | 54 mm |
| Stack | 498 mm | 502 mm | 524 mm | 540 mm | 550 mm | 575 mm | 609 mm |
| Reach | 356 mm | 364 mm | 374 mm | 386 mm | 396 mm | 406 mm | 416 mm |
| Top Tube Length | 500 mm | 513 mm | 531 mm | 547 mm | 560 mm | 578 mm | 598 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 590 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 80 mm | 80 mm | 100 mm | 115 mm | 125 mm | 150 mm | 185 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 971 mm | 971 mm | 981 mm | 993 mm | 1006 mm | 1020 mm | 1040 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
Model Overview
IZALCO MAX DISC 8.7 is part of the Focus Izalco model. There are 61 bikes that carry this model name. You can easily view all of the Focus Izalco bikes models from 2020, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Race bikes average weight
On a deeper look, we notice that the average weight of a Race bike is 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Focus IZALCO MAX DISC 8.7 it’s weighing 8.4 kg (18.52 lbs). At this weight, is much heavier than average. To sum up, it’s 23.17% heavier than the average weight of Race bikes.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
IZALCO MAX DISC 8.7 components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the IZALCO MAX DISC 8.7 model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The IZALCO MAX DISC 8.7 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 7 sizes. They vary from 157 cm – 204 cm (5.15 ft – 6.69 ft). In conclusion, you won’t have a problem finding one that suits you.
