Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MAX technology carbon, disc, BB86, 142x12 mm thru axle, R.A.T Evo technology, electronical shifting only, flat mount 160 mm, internal cable routing
Suspension Fork
MAX technology carbon, integrated, disc, 100x12 mm, thru axle, R.A.T Evo Technology, flat mount 160/140 mm, internal brake cable routing
Drivetrain
Rear Derailleur
Shimano Dura-Ace R9150 Di2
Front Derailleur
Shimano Dura-Ace R9150, Di2
Shift Levers
Shimano Dura Ace R9170, Di2
Cassette
Shimano Dura-Ace R9100
Crank
Shimano Dura Ace R9100, 52/36T
Bottom Bracket
Shimano Pressfit Road BB86
Chain
Shimano CN-HG901
Wheels
Rims
DT Swiss ARC 1450 DICUT DB, 48mm height
Tires
Vittoria Corsa, 700 x 25C, Folding
Brakes
Brakes
Shimano Dura Ace R9170 hydraulic disc
Brake Levers
Shimano Dura Ace R9170, Di2
Cockpit
Stem
Izalco Max carbon, integrated cable routing, 31.8mm, -15 degree
Handlebar
Easton EC90 Aero, carbon, drop: 125mm, reach: 80mm
Grips
FOCUS Bartape SL
Headset
Acros, IS 52/40-IS52/42
Seat
Saddle
Prologo Dimension
Seatpost
FOCUS IZALCO MAX aero carbon, D-shape, 350 mm, set-back: 15mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.38 mm | 1.4 mm | 1.4 mm | 1.39 mm | 1.42 mm | 1.46 mm |
| Bottom Bracket Height | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm | 258 mm |
| Front Center | 578 mm | 578 mm | 588 mm | 600 mm | 612 mm | 626 mm | 646 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 71 mm | 66 mm | 59 mm | 57 mm | 57 mm | 52 mm | 54 mm |
| Stack | 498 mm | 502 mm | 524 mm | 540 mm | 550 mm | 575 mm | 609 mm |
| Reach | 356 mm | 364 mm | 374 mm | 386 mm | 396 mm | 406 mm | 416 mm |
| Top Tube Length | 500 mm | 513 mm | 531 mm | 547 mm | 560 mm | 578 mm | 598 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 590 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 80 mm | 80 mm | 100 mm | 115 mm | 125 mm | 150 mm | 185 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 971 mm | 971 mm | 981 mm | 993 mm | 1006 mm | 1020 mm | 1040 mm |
| Bottom Bracket Drop | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
About this model
IZALCO MAX DISC 9.9 is part of the Focus Izalco model. Focus launched 61 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Race bikes
Race bikes have an average weight of 6.82 kg (15.04 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 7.5 kg (16.53 lbs), the IZALCO MAX DISC 9.9 model is a bit heavier than average. In short, the average Race bike weight is 9.97% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
IZALCO MAX DISC 9.9 components
Fork material
IZALCO MAX DISC 9.9 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the IZALCO MAX DISC 9.9 bike is equipped with the 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The IZALCO MAX DISC 9.9 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Focus IZALCO MAX DISC 9.9 bike has 7 sizes, in the range of 157 cm – 204 cm (5.15 ft – 6.69 ft). In conclusion, you won’t have a problem finding one that suits you.
