Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery 756 Wh (378 Wh internal, 378 Wh external T.E.C. Pack) -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Suspension Fork
Rock Shox Recon RL, 110x15 mm QR
Rear Shock
RockShox Deluxe Select, 210/55 mm, hardware: 25,0 x 8mm, custom tune
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1210 Eagle, 12-speed
Crank
Shimano FC-E8000
Bottom Bracket
-
Chain
SRAM SX Eagle
Wheels
Front Hub
Novatec D041, 15x110 mm thru axle
Rear Hub
Novatec D162 Disc, 12x148 mm
Rims
RaceFace AR30 Offset
Tires
Maxxis Rekon 2.6 3C EXO TR
Brakes
Brakes
Magura MT5, 4-piston (front) / MT4, 2-piston (rear)
Brake Levers
Magura MT5 (front) / Magura MT4 (rear)
Cockpit
Stem
BBB Jumper BHS-138, 31.8 mm
Handlebar
BBB Ascension BHB-110-Di2, aluminium, riserbar, 780mm, rise: 20mm, backsweep: 9degree
Grips
FOCUS Locker SL
Headset
Acros AZX-212 AH, 1-1/8", tapered, 44/286-ZS56/40
Seat
Saddle
FOCUS Trail SL
Seatpost
Kind Shock E30i, 31,6mm
Motor & Battery
Motor
Shimano Steps E8000, 70 Nm, 250 W
Battery
756 Wh (378 Wh internal, 378 Wh external T.E.C. Pack)
Remote
Shimano Steps E7000, black/white LCD display, walk assist, bluetooth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.44 mm | 1.44 mm | 1.43 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 726 mm | 746 mm | 761 mm | 792 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 107 mm | 107 mm | 115 mm | 107 mm |
| Stack | 611 mm | 611 mm | 629 mm | 647 mm |
| Reach | 403 mm | 423 mm | 438 mm | 453 mm |
| Top Tube Length | 575 mm | 595 mm | 615 mm | 640 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1188 mm | 1208 mm | 1223 mm | 1254 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
JAM² 6.6 NINE completes the Focus E Jam model. Focus released 45 e-bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Focus JAM² 6.6 NINE it’s weighing 22.1 kg (48.72 lbs). At this weight, is a bit lighter than average. In other words, this model is 5.97% lighter than the average Enduro e-bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The JAM² 6.6 NINE comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this e-bike has the RockShox Deluxe Select model, with a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The JAM² 6.6 NINE 2020 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The JAM² 6.6 NINE has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the JAM² 6.6 NINE. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
