Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 150mm -
Fork RockShox Recon Silver RL
-
Groupset SLX, FSA -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery 625 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 203 mm
Suspension Fork
Rock Shox Recon RL 29 Boost, E-MTB, 110x15 mm, 51 mm rake, 130 mm travel
Rear Shock
RockShox Deluxe Select, 210/55 mm, hardware: 25,0 x 8mm, custom tune
Drivetrain
Rear Derailleur
Shimano SLX M7100, 12-speed
Shift Levers
Shimano SLX M7100, 12-speed
Cassette
Shimano SLX M7100, 12-speed
Crank
FSA CK-320, aluminium
Bottom Bracket
-
Chain
Shimano SLX CN-M7100
Wheels
Front Hub
Novatec D041, 15x110 mm thru axle
Rear Hub
Novatec D162 Disc, 12x148 mm
Rims
RaceFace AR30 Offset
Tires
Maxxis Minion DHF 2.6 Dual EXO TR
Brakes
Brakes
Shimano BR-MT520, 4 piston
Brake Levers
Shimano BR-MT520
Cockpit
Stem
BBB Jumper BHS-138, 31.8 mm
Handlebar
BBB Ascension BHB-110, aluminium, riserbar, 780mm, rise: 20mm, backsweep: 9degree
Grips
FOCUS Locker SL
Headset
VP Components, ZS56/28,6-ZS56/40
Seat
Saddle
FOCUS Trail SL
Seatpost
Kind Shock E30i, 31,6mm
Motor & Battery
Motor
Bosch Performance CX Gen4, 75 Nm, 250 W
Battery
625 Wh
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.445 mm | 1.375 mm | 1.33 mm | 1.301 mm |
| Bottom Bracket Height | 364 mm | 364 mm | 364 mm | 364 mm |
| Front Center | 736 mm | 763 mm | 794 mm | 827 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 116 mm | 116 mm | 116 mm | 116 mm |
| Stack | 607 mm | 612 mm | 625 mm | 644 mm |
| Reach | 420 mm | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 573 mm | 600 mm | 630 mm | 661 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 115 mm | 130 mm | 150 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1163 mm | 1190 mm | 1221 mm | 1254 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm | 10 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
JAM² 6.7 NINE is a Focus E Jam model. Focus released 45 e-bikes variations of this model so far. You can easily view all of the Focus E Jam e-bikes models from 2020, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 23.5 kg (51.81 lbs), the JAM² 6.7 NINE model is slightly heavier than average. In conclusion, the average Enduro e-bike weighs 0.34% less than JAM² 6.7 NINE.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
JAM² 6.7 NINE components
Fork
The JAM² 6.7 NINE comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The JAM² 6.7 NINE has a rear shock with a travel of 150mm. The model RockShox Deluxe Select is the one installed in this e-bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Focus JAM² 6.7 NINE 2020, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The JAM² 6.7 NINE has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Focus JAM² 6.7 NINE includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
