Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Marzocchi Bomber Z1
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery 756 Wh (378 Wh internal, 378 Wh external T.E.C. Pack) -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Suspension Fork
Marzocchi Bomber Z1, 3-position lever, 15x110 mm QR
Rear Shock
FOX Float DPS Performance, 3-position lever, 210/55 mm, hardware: 25,0 x 8mm, custom tune
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano SLX M7100, 12-speed
Crank
Shimano FC-E8000
Bottom Bracket
-
Chain
Shimano SLX CN-M7100
Wheels
Rims
Mavic E-XA Drifter (29" front / 27,5"+ rear), 622-30 / 584-35, 110x15 mm / 148x12 mm
Tires
Maxxis Minion DHF 2.6 3C Exo TR
Brakes
Brakes
Shimano XT M8120, 4 piston
Brake Levers
Shimano XT M8120, 4 piston
Cockpit
Stem
Race Face Aeffect R 35, 50mm
Handlebar
RaceFace Chester 35, aluminium, 780mm, rise: 35mm, backsweep: 8degree
Grips
Race Face Grippler
Headset
Acros AZX-212 AH, 1-1/8", tapered, 44/286-ZS56/40
Seat
Saddle
Proxim W350
Seatpost
Kind Shock E30i, 31,6mm
Motor & Battery
Motor
Shimano Steps E8000, 70 Nm, 250 W
Battery
756 Wh (378 Wh internal, 378 Wh external T.E.C. Pack)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.44 mm | 1.44 mm | 1.43 mm |
| Front Center | 726 mm | 746 mm | 761 mm | 792 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 107 mm | 107 mm | 115 mm | 107 mm |
| Stack | 611 mm | 611 mm | 629 mm | 647 mm |
| Reach | 403 mm | 423 mm | 438 mm | 453 mm |
| Top Tube Length | 575 mm | 595 mm | 615 mm | 640 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 120 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1188 mm | 1208 mm | 1223 mm | 1254 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
JAM² 6.9 DRIFTER completes the Focus E Jam2 model. Focus released 54 e-bikes variations of this model so far. Take a sneak peek at all Focus E Jam2 e-bikes models from 2020, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Enduro e-bikes
Enduro e-bikes weigh an average of 23.42 kg (51.63 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Focus JAM² 6.9 DRIFTER it’s weighing 21.7 kg (47.84 lbs). At this weight, is a bit lighter than average. To sum up, it’s 7.93% lighter than the average weight of Enduro e-bikes.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
JAM² 6.9 DRIFTER components
Fork
This e-bike has the Marzocchi Bomber Z1 fork installed. The fork’s travel is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Focus JAM² 6.9 DRIFTER e-bike has the FOX Float DPS Performance model installed, and has a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the JAM² 6.9 DRIFTER e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Focus JAM² 6.9 DRIFTER has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Focus JAM² 6.9 DRIFTER comes with a dropper post. Therefore, climbing or descending will be a breeze.
