Focus RAVEN 8.7 2023
2023 Mountain
Estimate price |
2,558$
Weight | 13.4 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Fork RockShox Judy Silver TK -
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon technology frame, BSA, 148x12 mm thru axle, internal cable routing, cockpit integration solution C.I.S. internal compartment Solution I.C.S. angle headset, Post Mount 160 mm
Suspension Fork
Rock Shox Judy Silver TK 29, 110x15 mm, 46 mm rake
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1230 NX Eagle, 12-speed
Crank
SRAM SX Eagle
Bottom Bracket
BSA
Chain
SRAM SX Eagle, 12-speed
Wheels
Front Hub
Novatec D041, 15x110 mm
Rear Hub
Novatec D462, 12x148 mm
Rims
RODI TRYP25, 25-622
Tires
Maxxis Rekon, 61-622
Brakes
Brakes
Disc
Brake Levers
SRAM Level
Cockpit
Stem
FOCUS C.I.S. 2.0 MTB integrated, 31.8 mm, aluminium
Handlebar
Aluminium, 760 mm, flatbar, backsweep: 9°, 31,8 mm
Headset
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated, 1.5/1.5" angle headset
Seat
Saddle
Selle Royal Groove SRX
Seatpost
Aluminium, 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.523 mm | 1.436 mm | 1.413 mm | 1.379 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 697 mm | 722 mm | 750 mm | 782 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 130 mm | 130 mm | 131 mm |
| Stack | 632 mm | 632 mm | 650 | 669 mm |
| Reach | 415 mm | 440 mm | 460 mm | 485 mm |
| Top Tube Length | 596 mm | 621 mm | 646 mm | 676 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1124 mm | 1149 mm | 1177 mm | 1209 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
RAVEN 8.7 completes the Focus Raven model. There are 29 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Focus RAVEN 8.7 2023 is the most economical model, with a starting price of 2335$. Focus RAVEN 8.9 2023 on the other hand costs 3821$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 2335$. Doing a quick comparison, we notice that RAVEN 8.7 price is 22.57% more expensive than the average cost of a Crosscountry bike.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
a bit heavier than average, RAVEN 8.7 has a weight of 13.4 kg (29.54 lbs). In short, the average Crosscountry bike weight is 8.06% lower than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The RAVEN 8.7 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on RAVEN 8.7 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Focus RAVEN 8.7 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
