Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset XT, Deore -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon frame, PF30 BB, 142x12 mm through axle, internal cable routing, Post Mount 160 mm
Suspension Fork
RockShox 30 Gold RL, OneLoc remote, 100x9 mm QR, 100 mm travel
Drivetrain
Rear Derailleur
Shimano Deore XT 785, 10-speed
Shift Levers
Shimano Deore M6000
Bottom Bracket
PF30, press-fit
Wheels
Rims
Rodi Viper 21, 27" 584-21, 29" 622-21, Shimano Deore CL, 142x12 mm / 100x9 mm QR
Tires
Continental Race King SL 2.2
Brakes
Brakes
Shimano BR-M315, 180 mm / 160 mm
Cockpit
Stem
BBB, aluminium, 31.8mm
Handlebar
BBB, aluminium, flatbar, 720mm, rise: 0mm, backsweep: 9degree
Seat
Seatpost
BBB, fixed, aluminium, Ø 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.48 mm | 1.44 mm | 1.43 mm | 1.43 mm |
| Bottom Bracket Height | 327 mm | 306 mm | 306 mm | 306 mm | 306 mm |
| Front Center | 653 mm | 674 mm | 690 mm | 713 mm | 734 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 93 mm | 91 mm | 91 mm | 90 mm | 91 mm |
| Stack | 577 mm | 617 mm | 620 mm | 641 mm | 660 mm |
| Reach | 402 mm | 417 mm | 432 mm | 447 mm | 462 mm |
| Top Tube Length | 563 mm | 589 mm | 605 mm | 626 mm | 646 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 69.5 ° | 69.8 ° | 69.8 ° | 69.8 ° | 69.8 ° |
| Head Tube Length | 100 mm | 104 mm | 107 mm | 130 mm | 150 mm |
| Chainstay Length | 422 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1071 mm | 1097 mm | 1113 mm | 1136 mm | 1157 mm |
| Bottom Bracket Drop | 47 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
RAVEN Elite completes the Focus Raven model. 29 bikes variations carry this model name so far. You can easily view all of the Focus Raven bikes models from 2018, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
RAVEN Elite components
Fork
Focus RAVEN Elite 2018 bike is equipped with the RockShox 30 Silver TK fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on RAVEN Elite are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RAVEN Elite comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Focus RAVEN Elite bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
