Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 170mm -
Fork Fox Rhythm Float 36
-
Groupset X01 Eagle, Truvativ Descendant -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon front and rear triangle, 170mm F.O.L.D. kinematic, ISCG 05, PF30 BB, 148x12 thru axle, internal cable routing, Post Mount 180 mm
Suspension Fork
FOX 36 Float Rhythm 27.5, Grip Remote, 110x15 mm, 44 mm rake, 170 mm travel
Rear Shock
FOX Float DPX2 Performance, 3-position lever, 230/65 mm, hardware: 30,0 x 8 mm, custom tune
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Shift Levers
SRAM X01 Eagle
Cassette
SRAM PG-1230 Eagle, 12-speed
Crank
Truvativ Descendant 6K DUB, 32T
Bottom Bracket
PF92 BB
Chain
SRAM GX Eagle
Wheels
Rims
DT Swiss E1900, 584-30, 15x110 mm / 12x148 mm
Tires
Maxxis Assegai 2.5 3C MaxxTerra Exo+ TR
Brakes
Brakes
SRAM Code RSC, 200 mm / 180 mm
Brake Levers
SRAM CODE RSC
Cockpit
Stem
RaceFace Turbine R, aluminium, 35,0mm
Handlebar
RaceFace Chester 35, aluminium, 780mm, rise: 35mm, backsweep: 8degree
Grips
BBB Python BHG-95
Headset
Acros AIX-322, tapered, IS 42/286-IS52/40
Seat
Saddle
FOCUS Trail SL
Seatpost
KindShock E30i, 31,6mm, internal
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.429 mm | 1.386 mm | 1.354 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 742 mm | 767 mm | 793 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 121 mm | 121 mm | 121 mm |
| Stack | 600 mm | 610 mm | 623 mm |
| Reach | 420 mm | 440 mm | 460 mm |
| Top Tube Length | 581 mm | 603 mm | 628 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm |
| Head Tube Angle | 64.8 ° | 64.8 ° | 64.8 ° |
| Head Tube Length | 106 mm | 115 mm | 130 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1170 mm | 1195 mm | 1221 mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
SAM 8.8 is part of the Focus Sam model. Focus released 14 bikes variations of this model so far. Take a sneak peek at all Focus Sam bikes models from 2020, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Enduro bikes average weight
Enduro bikes have an average weight of 14.27 kg (31.46 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly heavier than average, SAM 8.8 has a weight of 14.6 kg (32.19 lbs). To sum up, it’s 2.31% heavier than the average weight of Enduro bikes.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
SAM 8.8 components
Fork
The SAM 8.8 comes factory-installed with the Fox Rhythm Float 36 fork. This has a travel range of 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float DPX2 Performance model, with a travel of 170mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on SAM 8.8 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Focus SAM 8.8 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Focus SAM 8.8 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
