Focus SAM² 6.0 2023
2023 E-bike
Estimate price |
10,120$
Weight | 26.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Rear 170mm -
Fork Fox Factory Float 38 -
Groupset XT, Race Face -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. Gen2, 148x12 mm thru axle, internal cable routing, post mount 203 mm
Suspension Fork
FOX 38 Factory Float 29, Grip 2, E-Bike+, 110x15 mm, 44 mm rake
Rear Shock
FOX DHX Performance Coil, 230/65 mm, hardware: 20,0 x 8.0 mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano SLX M7100, 12-speed
Crank
RaceFace Aeffect R e-Optimized Bosch G4
Bottom Bracket
Integrated in Drive Unit
Chain
Shimano SLX CN-M7100, 12-speed
Wheels
Rims
MAVIC E-DEEMAX 30, 622-30, 148x12 mm / 110x15 mm
Tires
Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622
Brakes
Brakes
Disc
Brake Levers
Shimano XT M8120, 4 piston
Cockpit
Stem
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
Handlebar
RaceFace Atlas 35, aluminium, 820 mm, rise: 35 mm, backsweep: 8°
Headset
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset
Seat
Saddle
Fizik Terra Aidon
Seatpost
Post Moderne dropper post PM-214, 34.9 mm
Motor & Battery
Motor
Bosch Performance Line CXR Smart System, 36 V / 250 W / 85 Nm
Battery
750 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.32 mm | 1.29 mm | 1.25 mm |
| Front Center | 780 mm | 810 mm | 844 mm | 883 mm |
| Rake | 35 mm | 35 mm | 35 mm | 35 mm |
| Trail | 148 mm | 148 mm | 148 mm | 148 mm |
| Stack | 630 mm | 630 mm | 648 mm | 666 mm |
| Reach | 447 mm | 477 mm | 502 mm | 532 mm |
| Top Tube Length | 585 mm | 615 mm | 644 mm | 678 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 440 mm | 460 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 100 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1236 mm | 1266 mm | 1300 mm | 1339 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SAM² 6.0 belongs to the Focus E Sam2 model. 17 e-bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Focus SAM² 6.7 2023 is the most affordable e-bike of this model and has a price of 6157$. On the other hand, Focus SAM² 6.0 2023, is the most expensive and costs 9236$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 9236$. If we compare this with the average Enduro e-bike cost we notice that the price is 93.02% higher.
Average weight for Enduro e-bikes
On a deeper look, we notice that the average weight of an Enduro e-bike is 23.42 kg (51.63 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
SAM² 6.0 weighs 26.4 kg (58.2 lbs) and is considerably heavier than the average. In conclusion, the average Enduro e-bike weighs 12.72% less than SAM² 6.0.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
SAM² 6.0 components
Fork
Focus SAM² 6.0 2023 e-bike is equipped with the Fox Factory Float 38 fork, and has mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this e-bike has the FOX DHX Performance Coil model, with a travel of 170mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Focus SAM² 6.0 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
SAM² 6.0 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Focus model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
