Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Fork Fox Factory Float 36
-
Groupset EX1, SRAM -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery 10,5 Ah -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. kinematic, 148x12 mm through axle, internal cable routing, post mount 180 mm
Suspension Fork
Fox 36 Factory, 110x15 mm QR, 170 mm travel
Rear Shock
Fox DPS Factory, 230/67, hardware: shaft25,0x8 mm/body25,0x8 mm, custom tune
Drivetrain
Rear Derailleur
SRAM EX1, 8-speed
Shift Levers
SRAM EX
Crank
1x
Wheels
Rims
Race Face Turbine 584-30, 148x12 mm / 110x15 mm
Tires
Minion DHF 2.5 3C/TR/ EXO, foldable,
Brakes
Brakes
SRAM Code RSC, 200 mm / 180 mm
Cockpit
Stem
BBB, aluminium, Di2, 31.8 mm, 55 mm
Handlebar
BBB, aluminium, Di2, riserbar, 760mm, rise: 20mm, backsweep: 9degree
Seat
Seatpost
Fox Transfer Factory 31,6mm, internal, 1by remote
Motor & Battery
Motor
Shimano Steps E8000, 70 Nm, 250 W
Battery
10,5 Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.37 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm |
| Front Center | 741 mm | 762 mm | 785 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 127 mm | 121 mm | 122 mm |
| Stack | 610 mm | 610 mm | 628 mm |
| Reach | 428 mm | 443 mm | 458 mm |
| Top Tube Length | 588 mm | 607 mm | 627 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 118 mm | 118 mm | 138 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1199 mm | 1220 mm | 1243 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
SAM² Pro is part of the Focus E Sam2 model. 17 e-bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 36 model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Focus SAM² Pro 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SAM² Pro comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
SAM² Pro comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
Dropper post
Focus SAM² Pro includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
