Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Acera, Tourney -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminium, BSA BB, international disc brake standard
Suspension Fork
SR Suntour XCT DS, 9 mm QR, coil spring, 100 mm travel
Drivetrain
Rear Derailleur
Shimano Acera M360, 8-speed
Front Derailleur
Shimano TY700
Shift Levers
Shimano ST-EF505
Cassette
Shimano HG-200, 12-32T
Crank
Shimano TY301
Bottom Bracket
BSA
Chain
KMC X8.93
Wheels
Front Hub
Shimano DH-3D37, dynamo hub, QR
Rear Hub
Shimano TX505, QR
Rims
Schürmann YAK 21
Tires
Impac Ridgepac 2.1
Brakes
Brakes
Shimano MT200, hydraulic disc brake
Brake Levers
Shimano MT200
Cockpit
Stem
aluminium, 31.8mm
Handlebar
aluminium, riserbar, 720mm
Grips
FOCUS SL
Headset
VP Components
Seat
Saddle
FOCUS Sport
Seatpost
Alloy, 27,2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.58 mm | 1.57 mm | 1.57 mm | 1.54 mm | 1.54 mm | 1.53 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 326 mm | 326 mm | 326 mm | 326 mm | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 629 mm | 629 mm | 642 mm | 642 mm | 655 mm | 655 mm | 677 mm | 677 mm | 693 mm | 693 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm | 93 mm | 93 mm | 93 mm | 93 mm | 94 mm | 94 mm |
| Stack | 584 mm | 584 mm | 594 mm | 594 mm | 616 mm | 616 mm | 634 mm | 634 mm | 654 mm | 654 mm |
| Reach | 369 mm | 369 mm | 379 mm | 379 mm | 399 mm | 399 mm | 414 mm | 414 mm | 424 mm | 424 mm |
| Top Tube Length | 544 mm | 544 mm | 556 mm | 556 mm | 577 mm | 577 mm | 597 mm | 597 mm | 613 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 360 mm | 360 mm | 400 mm | 400 mm | 460 mm | 460 mm | 500 mm | 500 mm | 540 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 110 mm | 110 mm | 130 mm | 130 mm | 150 mm | 150 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1048 mm | 1048 mm | 1062 mm | 1062 mm | 1089 mm | 1089 mm | 1111 mm | 1111 mm | 1127 mm | 1127 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
About this model
WHISTLER 3.5 EQP belongs to the Focus Whistler model. Focus launched 34 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 16.6 kg (36.6 lbs), the WHISTLER 3.5 EQP model is much heavier than average. In short, the average Crosscountry bike weight is 33.87% lower than this one.
WHISTLER 3.5 EQP components
Fork
This bike has the SunTour XCT fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the WHISTLER 3.5 EQP bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 10 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
