Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Fork RockShox 30 Silver TK -
Groupset XT, Altus -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminium, BSA BB, international disc brake standard
Suspension Fork
RockShox XC 30 TK, 9 mm QR, lockout
Drivetrain
Rear Derailleur
Shimano Deore XT M772
Front Derailleur
Shimano Altus M2000
Shift Levers
Shimano Altus M2010
Cassette
Shimano HG200 11-36T
Crank
Shimano MT101
Bottom Bracket
BSA
Chain
KMC X9
Wheels
Front Hub
Shimano TX505, QR
Rear Hub
Shimano TX505, QR
Rims
Schuermann YAK19
Tires
Schwalbe Smart Sam 2.25
Brakes
Brakes
Shimano MT200, hydraulic disc brake
Brake Levers
Shimano MT200
Cockpit
Stem
aluminium, 31.8mm
Handlebar
aluminium, riserbar, 720mm
Grips
FOCUS SL
Headset
VP Components
Seat
Saddle
FOCUS Sport
Seatpost
Alloy, 27,2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.58 mm | 1.57 mm | 1.57 mm | 1.54 mm | 1.54 mm | 1.53 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 326 mm | 326 mm | 326 mm | 326 mm | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 629 mm | 629 mm | 642 mm | 642 mm | 655 mm | 655 mm | 677 mm | 677 mm | 693 mm | 693 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm | 93 mm | 93 mm | 93 mm | 93 mm | 94 mm | 94 mm |
| Stack | 584 mm | 584 mm | 594 mm | 594 mm | 616 mm | 616 mm | 634 mm | 634 mm | 654 mm | 654 mm |
| Reach | 369 mm | 369 mm | 379 mm | 379 mm | 399 mm | 399 mm | 414 mm | 414 mm | 424 mm | 424 mm |
| Top Tube Length | 544 mm | 544 mm | 556 mm | 556 mm | 577 mm | 577 mm | 597 mm | 597 mm | 613 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 360 mm | 360 mm | 400 mm | 400 mm | 460 mm | 460 mm | 500 mm | 500 mm | 540 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 110 mm | 110 mm | 130 mm | 130 mm | 150 mm | 150 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1048 mm | 1048 mm | 1062 mm | 1062 mm | 1089 mm | 1089 mm | 1111 mm | 1111 mm | 1127 mm | 1127 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
About this model
WHISTLER 3.7 is part of the Focus Whistler model. 34 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
considerably heavier than average, WHISTLER 3.7 has a weight of 14.4 kg (31.75 lbs). To sum up, it’s 10.94% heavier than the average weight of Trail bikes.
WHISTLER 3.7 components
Fork
The WHISTLER 3.7 comes factory-installed with the RockShox 30 Silver TK fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the WHISTLER 3.7 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The WHISTLER 3.7 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 10 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
