Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver TK
-
Groupset SLX, Shimano -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminium, BSA BB, international disc brake standard
Suspension Fork
Rock Shox Recon RL, 100x9 mm QR, coil spring,Rock Shox Recon Silver TK 29, coil spring, 100x9 mm QR, 51 mm rake, 100mm travel
Drivetrain
Rear Derailleur
Shimano SLX M7100, 12-speed
Shift Levers
Shimano SLX M7100, 12-speed
Cassette
Shimano SLX M7100, 12-speed
Crank
Shimano MT610
Bottom Bracket
BSA
Chain
Shimano SLX CN-M7100
Wheels
Front Hub
Shimano TX505, QR
Rear Hub
Shimano MT401, QR
Rims
Schürmann YAK 21
Tires
Schwalbe Smart Sam 2.25
Brakes
Brakes
Shimano MT200, hydraulic disc brake
Brake Levers
Shimano MT200
Cockpit
Stem
aluminium, 31.8mm
Handlebar
aluminium, riserbar, 720mm
Grips
FOCUS SL
Headset
VP Components
Seat
Saddle
FOCUS Sport
Seatpost
Alloy, 27,2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.58 mm | 1.57 mm | 1.57 mm | 1.54 mm | 1.54 mm | 1.53 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 326 mm | 326 mm | 326 mm | 326 mm | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 629 mm | 629 mm | 642 mm | 642 mm | 655 mm | 655 mm | 677 mm | 677 mm | 693 mm | 693 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm | 93 mm | 93 mm | 93 mm | 93 mm | 94 mm | 94 mm |
| Stack | 584 mm | 584 mm | 594 mm | 594 mm | 616 mm | 616 mm | 634 mm | 634 mm | 654 mm | 654 mm |
| Reach | 369 mm | 369 mm | 379 mm | 379 mm | 399 mm | 399 mm | 414 mm | 414 mm | 424 mm | 424 mm |
| Top Tube Length | 544 mm | 544 mm | 556 mm | 556 mm | 577 mm | 577 mm | 597 mm | 597 mm | 613 mm | 613 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 360 mm | 360 mm | 400 mm | 400 mm | 460 mm | 460 mm | 500 mm | 500 mm | 540 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 110 mm | 110 mm | 130 mm | 130 mm | 150 mm | 150 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1048 mm | 1048 mm | 1062 mm | 1062 mm | 1089 mm | 1089 mm | 1111 mm | 1111 mm | 1127 mm | 1127 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
Model Overview
WHISTLER 3.9 completes the Focus Whistler model. 34 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
considerably heavier than average, WHISTLER 3.9 has a weight of 13.7 kg (30.2 lbs). In conclusion, the average Crosscountry bike weighs 10.48% less than WHISTLER 3.9.
Overview of components
Fork
The RockShox Recon Silver TK is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The WHISTLER 3.9 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Focus WHISTLER 3.9 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Focus WHISTLER 3.9 bike has 10 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
