Forestal Cyon Halo 2022
2022 E-bike
Estimate price |
11,283$
Weight | 17 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Pike Select
-
Groupset GX Eagle, Praxis -
Suspension Full -
Motor Forestal 250W 60Nm mid-drive -
Battery Forestal Aurora Performance 360Wh / 52V / Integrated / Rapid Charge / 1.8kg / 350 x 72 x 50.5mm -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Forestal Alpha Box Carbon Trail 29" TR 150 Monocoque construction / Track Ready / 150mm Travel / 2.2kg Size M
Suspension Fork
Rockshox Pike Select 29" 150mm Charger RC / DebonAir / Tapered / Boost 15x110 / Maxle Stealth / Offset 42mm / Extl Rebound / Low Speed Compression / Gloss Black
Rear Shock
Rockshox Super Deluxe Select+ Metric 230x60mm / Debonair / Extl Rebound / 2 position compression / Custom tune / Black
Drivetrain
Rear Derailleur
SRAM GX Eagle 12 Speed / X-Actuation / Long cage / Colour: Lunar
Shift Levers
SRAM GX Eagle 12 Speed / X-Actuation / Colour: Lunar
Cassette
SRAM Eagle XG-1275 10-50T / 12 Speed / XD Driver Body / Colour: Black
Crank
Praxis Carbon Q-Factor 170mm / ISIS Drive / 104 BCD / Length 160mm Sizes S, M / Length 165mm Sizes L, XL
Chain
SRAM GX Eagle 12 Speed / Powerlock / Colour: Silver-Black
Wheels
Rims
Front: Crankbrothers Synthesis Alloy 29" Enduro Hub CB / 15 x 110mm Boost / Spokes Sapim E-Light / 6-Bolt / Inner Rim 31.5mm / Outter Rim 37.5mm, Rear: Crankbrothers Synthesis Alloy 29" Enduro Hub CB / 12 x 148mm Boost / Spokes Sapim Strong / XD Drivetrain/ 6-Bolt / Inner Rim 29.5mm / Outter Rim 36.5mm
Tires
Front: Panaracer Romero 29 x 2.4 3Comp. Tubeless Ready / Triple Compound / Puncture resistant wall, Rear: Panaracer Romero 29 x 2.4 3Comp. Tubeless Ready / Triple Compound / Puncture resistant wall
Brakes
Brakes
Magura MT5
Cockpit
Stem
Forestal Oxydon 45mm ? 31.8mm / 7075 Heavy duty Aluminum
Handlebar
Forestal Oxydon C 780mm ? 31.8mm / Upsweep 4° / Backsweep 6° / Rise 15mm / Toray T700 & T800 Carbon
Grips
Production Privée CR35 Forestal x Production Privée edition / 2-position adjustable (Tour / Race)
Headset
Acros Integrated ZS 56 Top / ZS 56 Bottom / Internal cable routing / Stainless steel bearings / Blocklock 150°
Seat
Saddle
Fizik Aidon X3 E-MTB Fibre reinforced nylon / S-alloy rails / 249g / 255 x 145mm
Seatpost
Crankbrothers Highline 7 ? 31.6mm / Length 125mm Size S / Length 150mm Sizes M, L / Length 170mm Size XL / Black ring / Aluminum 7076 T6
Motor & Battery
Motor
Forestal EonDrive 250W / 60Nm / IP67 / 1.95kg / 165 x 105 x 147mm
Battery
Forestal Aurora Performance 360Wh / 52V / Integrated / Rapid Charge / 1.8kg / 350 x 72 x 50.5mm
Remote
Forestal Smart Trigger 3 Buttons / Battery & Assistance LED Indicators
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.36 mm | 1.3 mm | 1.28 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Front Center | 743 mm | 770 mm | 799 mm | 825 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 123 mm | 123 mm | 123 mm | 123 mm |
| Stack | 609 mm | 614 mm | 623 mm | 636 mm |
| Reach | 428 mm | 453 mm | 478 mm | 498 mm |
| Top Tube Length | 575 mm | 601 mm | 631 mm | 655 mm |
| Seat Tube Angle | 76.6 ° | 76.6 ° | 76.6 ° | 76.6 ° |
| Seat Tube Length | 415 mm | 430 mm | 465 mm | 500 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 433 mm | 433 mm | 443 mm | 443 mm |
| Wheelbase | 1174 mm | 1201 mm | 1240 mm | 1266 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Cyon Halo belongs to the Forestal E Cyon model. 9 e-bikes variations carry this model name so far. Take a sneak peek at all Forestal E Cyon e-bikes models from 2022, by clicking here.
Model range prices
Forestal Cyon Halo 2022 is the cheapest e-bike model and costs 10298$. Forestal Cyon Diode 2022 is the most expensive one and costs 15820$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2022 and its price was 10298$. Doing a quick comparison, we notice that Cyon Halo price is 115.21% higher than the average cost of an Enduro e-bike.
Enduro e-bikes average weight
Enduro e-bikes weigh an average of 23.42 kg (51.63 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Forestal Cyon Halo it’s weighing 17 kg (37.48 lbs). At this weight, is much lighter than average. In other words, this model is 37.76% lighter than the average Enduro e-bike.
Overview of components
Fork
The RockShox Pike Select is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Rockshox Super Deluxe Select+ Metric 230x60mm rear shock model, which has a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the Cyon Halo e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Forestal Cyon Halo includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
