Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom butted alloy
Suspension Fork
Fuji A1 alloy
Drivetrain
Rear Derailleur
Shimano Alivio shadow OR microSHIFT R9
Front Derailleur
Shimano Acera OR microSHIFT R9
Shift Levers
Shimano Altus, 2 x 9-speed OR microSHIFT R9 Xpress Shift
Cassette
Shimano Acera, 11-36T OR microSHIFT CS-H092
Crank
Shimano Altus, 46/30T OR Prowheel RPP
Bottom Bracket
Shimano sealed cartridge bearing
Chain
KMC X9
Pedals
Resin platform
Wheels
Rims
Alex double wall rims 32h, stainless spokes
Tires
Kenda Tendril, 700 x 38c, K-shield flat protection OR Goodyear Transit Tour, 700 x 40c
Brakes
Brakes
Tektro HD-275, hydraulic disc, 160mm rotors
Brake Levers
Tektro HD-275, hydraulic disc
Cockpit
Stem
3D-forged alloy, 17°, 31.8mm
Handlebar
Alloy, 18mm rise, 6° backsweep
Grips
Velo comfort sport
Headset
1-1/8" semi-integrated
Seat
Saddle
Selle Royal Vivo Ergo
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.48 mm | 1.55 mm |
| Front Center | 609 mm | 611 mm | 607 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 87 mm | 79 mm | 75 mm |
| Stack | 539 mm | 558 mm | 581 mm |
| Reach | 372 mm | 376 mm | 376 mm |
| Top Tube Length | 517 mm | 537 mm | 553 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1048 mm | 1050 mm | 1046 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 668 mm | 679 mm | 679 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Absolute 1.7 ST completes the Fuji Absolute model. Fuji released 167 bikes variations of this model so far. Take a sneak peek at all Fuji Absolute bikes models from 2023, by clicking here.
Model range prices
Fuji Absolute 2.3 2023 is the most affordable bike of this model and has a price of 385$. On the other hand, Fuji Absolute 1.3 ST 2023, is the most expensive and costs 1164$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Fuji released this model in 2023, its price was 879$. Comparing this to the average Fitness bike price, we see that the price is 33.99% more expensive.
Overview of components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Absolute 1.7 ST 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Absolute 1.7 ST comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Fuji Absolute 1.7 ST bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
