Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy w/ PowerCurve down tube, smooth welds, hydroformed top tube, tapered 1 1/8" - 1.5" head tube
Suspension Fork
SR Suntour SF15-XCT-HLO w/ hydraulic lockout, 80mm travel (13"-15") 100mm travel (17"-19")
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Alivio SGS, 9-speed
Front Derailleur
Shimano Altus, 34.9mm
Shift Levers
Shimano Altus, Rapid Fire, 9-speed
Cassette
Shimano HG200, 11-34T, 9-speed
Crank
Shimano Acera, 44/32/22T
Bottom Bracket
FSA, sealed cartridge bearing
Chain
KMC X9, w/ MissingLink, 9-speed
Pedals
Resin platform
Wheels
Rims
Vera Terra DPD18 rims 32h, Formula DC-20LW front / Formula DC-22LW rear disc hubs, 15g black spokes
Tires
Vera Eos, 27.5" x 2.2", 30 tpi
Brakes
Brakes
Tektro Novella, mechanical disc, 180mm/160mm rotor
Brake Levers
Alloy, 2-finger
Cockpit
Stem
Oval Concepts 313, 6061 3D-forged alloy, 31.8mm, 7° rise
Handlebar
Oval Concepts, flat alloy bar, 9° sweep, 31.8mm diameter, 680mm wide
Headset
FSA NO.42, 1 1/8" - 1.5", caged bearings
Seat
Saddle
Oval Concepts Womens w/ steel rails
Seatpost
Oval Concepts, 6061 alloy, 31.6, double-bolt micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.59 mm | 1.61 mm | 1.56 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 594 mm | 605 mm | 620 mm | 640 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 81 mm | 81 mm | 81 mm | 81 mm |
| Stack | 575.8 mm | 580.5 mm | 601.1 mm | 610.5 mm |
| Reach | 356.4 mm | 365.9 mm | 373.6 mm | 390.7 mm |
| Top Tube Length | 533.1 mm | 544 mm | 558 mm | 578 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 482 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1017 mm | 1028 mm | 1043 mm | 1064 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 684 mm | 740 mm | 773 mm | 794 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
Addy 27-5 1.7 Disc is part of the Fuji Addy model. There are 52 bikes that carry this model name. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Addy 27-5 1.7 Disc weighs 14.8 kg (32.63 lbs) and is much heavier than the average. In other words, this model is 19.35% heavier than the average Crosscountry bike.
Overview of components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Addy 27-5 1.7 Disc are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Addy 27-5 1.7 Disc has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
