Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 80mm -
Fork Manitou
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy w/ PowerCurve down tube, smooth welds, hydroformed top tube, tapered 1 1/8" - 1.5" head tube
Suspension Fork
Manitou Marvel 27.5 Pro ISO air w/ tapered alloy steerer, MILO lockout, 80mm travel (13"-15") 100mm travel (17"-19")
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT, M786 SGS Shadow, 10-speed
Front Derailleur
Shimano Deore, M616, 34.9mm
Shift Levers
Shimano Deore, M610i Rapid Fire, 10-speed
Cassette
Shimano Deore HG62, 11-36T, 10-speed
Crank
Shimano Deore, M615 w/ integrated spindle, 38/24T
Bottom Bracket
Shimano sealed cartridge
Chain
KMC X10, 10-speed
Pedals
N/A
Wheels
Rims
Formula CL-81 front / Formula CL-36 rear, 32H disc hubs, Sun Inferno 23 rims
Tires
Schwalbe Racing Ralph, 27.5" x 2.25" folding, 67 tpi
Brakes
Brakes
Shimano Deore M615 hydraulic, 180mm/160mm rotor
Brake Levers
Shimano Deore M615 hydraulic
Cockpit
Stem
Oval M313, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
Handlebar
Oval M250, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, +/- 5mm rise
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Oval Womens W600 w/ hollow CrMo rails
Seatpost
Oval M300, alloy double-bolt micro-adjust, 31.6mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.59 mm | 1.61 mm | 1.56 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 594 mm | 605 mm | 620 mm | 640 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 81 mm | 81 mm | 81 mm | 81 mm |
| Stack | 575.8 mm | 580.8 mm | 601.1 mm | 610.5 mm |
| Reach | 356.4 mm | 365.9 mm | 373.6 mm | 390.7 mm |
| Top Tube Length | 529.1 mm | 544 mm | 558 mm | 578 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 482 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 115 mm | 115 mm | 125 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1017 mm | 1028 mm | 1043 mm | 1064 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 689 mm | 718 mm | 761 mm | 787 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
Addy Race 27-5 1.1 belongs to the Fuji Addy model. Fuji released 52 bikes variations of this model so far. You can easily view all of the Fuji Addy bikes models from 2014, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 11.53 kg (25.42 lbs), the Addy Race 27-5 1.1 model is a bit lighter than average. In short, the average Crosscountry bike weight is 7.55% higher than this one.
Overview of components
Fork
The Addy Race 27-5 1.1 comes factory-installed with the Manitou fork. This has a travel range of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When it comes to wheels, the Addy Race 27-5 1.1 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Fuji Addy Race 27-5 1.1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
